STEERING

HYDRAULIC HELM PUMP - COMPRESSION STYLE HYDRAULIC STEERING KIT -Q/S
FITTINGS

8M0073922
8M0056140 Quicksilver 1.5 cu in displacement Std Helm kit with Cylinder and Hoses. (14 ft)
Front Mount Tilt helm ‑ 1.5 cu in (25 CC.) displacement. Approximately 5 turns Approximately 5 turns lock to lock on a single engine
lock to lock on singles Hydraulic Steering ‑ 75 HP engines and above (Use with Compression type
and 8 on dual cylinders hoses 8M0053473 thru 8M0053449)
Compact design
Built‑in valve for positive rudder lock 8M0073923
Integral relief valve for over pressure protection ‑ 1500 PSI (Use Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (16 ft)
Compression style fittings and hoses) Approximately 5 turns lock to lock on a single engine
Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression type
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic hoses 8M0053473 thru 8M0053449)
steering installation. 8M0073924
8M0056142 Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (18 ft)
Front Mount Tilt helm ‑ 2.0 cu in (33 CC.) displacement. Approximately 4.7 turns Approximately 5 turns lock to lock on a single engine
lock to lock on singles Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression type
and 7.3 on dual cylinders hoses 8M0053473 thru 8M0053449)
Compact design
Built‑in valve for positive rudder lock 8M0073925
Integral relief valve for over pressure protection ‑ 1500 PSI (Use Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (20 ft)
Compression style fittings and hoses) Approximately 5 turns lock to lock on a single engine
Use with cylinder 8M0050097 and hoses 8M0053474 thru 8M0053492. Use on Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression type
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic hoses 8M0053473 thru 8M0053449)
steering installation. 8M0073927
HYDRAULIC HELM PUMP -Q/S-TILT Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (22 ft)
Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression type
hoses 8M0053473 thru 8M0053449)
8M0073928
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses. (24 ft)
Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression type
hoses 8M0053473 thru 8M0053449)
QUICKSILVER® RIGGING Front Mount 2.4 cu in (39 CC) displacement. Approximately 3 turns lock to lock on
REMOTE FILL KIT FOR HYDRAULIC STEERING

8M0056144
singles (Use Compression style fittings and hoses)
and 6.5 on dual cylinders
Compact design
Tilt Range of 48 Deg and 5 locking positions
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 175‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can
be used on OptiMax with Mercury hydraulic cylinder and hoses Also can be used 64-889934A05
on 75‑115 4 stroke and 1.5L opti 75‑115 HP
Use cylinder 8M0050097 for Std and 8M0056145 for counter for multiple engine Remote fill adapter for rear mount and tilt mount Hydraulic pumps
installs. Hose series is 8M0053474 thru 8M0053492 Hydraulic Steering for Verado 135 to 200‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
