Page 473 - Quicksilver Product Guide (2020) - 8M0163242

FUEL SYSTEM QUICK DISCONNECT-TANK END

MERCURY®/MARINER®/FORCE®
QUICK DISCONNECT-TANK END

22- 13563Q 7 30185Q 3
Clip‑on style. Bayonet style
A double sealed clip‑on type disconnect for the fuel tank end and fits a 5/16" (8 Bayonet style push and turn type quick disconnect for the older 6.6 gallon fuel tank.
mm) I.D. fuel line. Priced individually, sold @ multiples of 3
Priced individually, sold @ multiples of 2 Quicksilver Branded, Clamshell Package Point of Sale Packaged.
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
QUICK DISCONNECT-ENGINE END
QUICK DISCONNECT-ENGINE END

30635Q 3
22- 14213Q Small twist lock type connector.
Used with older 1/4" I.D. Hose For Mercury/Mariner 3.9 thru 9.8 hp. Outboards (1971 and older) utilizing twist lock
Fits Force 40 hp. and larger (1993 and newer), Force 9.9/15/25 hp. (1998) and all type connector.
Mercury/Mariner outboards using clip on type disconnect at engine ends and 1/4" Priced individually, sold @ multiples of 3
I.D. (black) fuel line. Quicksilver Branded, Clamshell Package Point of Sale Packaged.
Priced individually, sold @ multiples of 2
Quicksilver Branded, Clamshell Package Point of Sale Packaged. QUICK DISCONNECT-ENGINE END
QUICK DISCONNECT-ENGINE END

22831Q 3
Twist lock type connector.
22- 13563Q 3 For Mercury/Mariner utilizing twist lock type connector (except Mercury 3.9 thru 9.8
Used with newer fuel line diameter. hp., 1971 and older).
Fits Force 40 hp. and larger (1993 and Newer), Force 9.9/15/25 hp. (1998) and all Priced individually, sold @ multiples of 3
Mercury/Mariner outboards using clip on type disconnect at engine ends and 5/16"
I.D (8 mm) fuel line. Quicksilver Branded, Clamshell Package Point of Sale Packaged.
Priced individually, sold @ multiples of 2
Quicksilver Branded, Clamshell Package Point of Sale Packaged.

464
