Page 471 - Quicksilver Product Guide (2020) - 8M0163242

FUEL SYSTEM BULK FUEL LINE

MERCURY®/MARINER®/FORCE®
9 FT. FUEL LINE ASSEMBLY

32-8M8026967 32-8M0038500
Low Permeation hose 9 ft. (2.74 m) 5/16" line with primer bulb, 2 snap clamps, and Low Permeation hose, 5/16 in. (8 mm) I.D. x 100 ft. (30.5 m) spool. (EPA
no end connectors. compliant).
Standard universal 5/16" (8 mm) I.D. fuel line can be adapted to many uses by Fits fuel line assemblies for delivering fuel from the fuel tank to the engine fuel
adding different connectors as desired. This assembly may be used in all connector.
applications not governed by US‑EPA 2011 regulations. 32-8M0038563
12 FT. FUEL LINE ASSEMBLY Low Permeation hose, 3/8 inch (9.5 mm) I.D. x 100 ft. (30.5 m) roll.
32-8M0054326 EPA Compliant.
Low Permeation (EPA compliant) hose 12 ft. (3.66 m) 5/16" line with a non‑EPA PRIMER BULB ASSEMBLY
compliant primer bulb, 2 snap clamps, and no end connectors.
Standard universal 5/16" (8 mm) I.D. fuel line can be adapted to many uses by
adding different connectors as desired. This assembly may be used in all
applications not governed by US‑EPA 2011 regulations.
Quicksilver Branded, Box Point of Sale Packaged.
12 FT. FUEL LINE ASSEMBLY

8M0054313
Using materials resistant to the chemistry of today's fuels, this bulb is designed to
remain pliable longer. Two hose clamps are included.
For use with our gray color, 5/16 in. (8 mm) I.D. fuel line & 3/8" I.D. fuel line. This
bulb may be used in all applications not governed by US‑EPA 2011 regulations.
Priced individually, sold @ multiples of 4
32-8M0054327 Quicksilver Branded, Box Point of Sale Packaged.
Low Permeation (EPA compliant) hose has double sealed quick connect type fitting PRIMER BULB ASSEMBLY
on tank end, and standard quick connect fitting on engine end. A non‑EPA
compliant primer bulb is included in this 12 ft. (3.66 m) assembly.
Fits Force 40 hp. and larger (1993 and Newer), Force 9.9/15/25 hp. (1998) and all
Mercury/Mariner outboards using clip‑on type disconnects at both tank and engine
ends. This assembly may be used in all applications not governed by US‑EPA
2011 regulations.
Quicksilver Branded, Box Point of Sale Packaged.
FUEL LINE ASSEMBLY- UNIVERSAL

8M0054315
For use with our 1/4 in. I.D. (black) fuel line. This bulb may be used in all
applications not governed by US‑EPA 2011 regulations.
Priced individually, sold @ multiples of 4
Quicksilver Branded, Box Point of Sale Packaged.

32-8M0038468
Fuel hose (only). CE certified 5/16" I.D. (.315 in. 8 mm) fuel line with no
connectors. 9 ft. (2.74 m) Premium fuel line for custom manufacturing fuel line
assemblies.

462
