FUEL SYSTEM

FUEL LINES AND PRIMER BULBS - (NON-US 8 FT. FUEL LINE ASSEMBLY
COMPLIANT)

These assemblies may be used in all applications not governed by the
US‑EPA 2011 regulations. If those regulations do apply, please refer to MERCURY®/MARINER®/FORCE®
a 2011 US Compliant Section either here or in an Accessories Guide for
applicable assemblies complete with provision for a pressurized fuel
tank and low permeation primer bulb.

8 FT. FUEL LINE ASSEMBLY

32-8M0054325
Low Permeation (EPA compliant) hose has double sealed quick connect type fitting
on tank end and clip‑on type quick connect on engine end. A non‑EPA compliant
primer bulb is included in this 8 ft. (2.44 m) assembly.
Fits Force 40 hp. and larger (1993 and Newer), Force 9.9/15/25 hp. (1998) and all
Mercury/Mariner outboards using clip‑on type disconnects at both tank and engine
ends. This assembly may be used in all applications not governed by US‑EPA
2011 regulations.
Quicksilver Branded, Box Point of Sale Packaged.
8 FT. FUEL LINE ASSEMBLY
32-8M0054323
Low Permeation (EPA compliant) hose has 1/8" NPT threaded fitting on engine end
and 1/4" NPT threaded fitting on the tank end. A non‑EPA compliant primer bulb is
included in this 8 ft. (2.44 m) assembly.
Fits varying applications using the older style twist type disconnects at the engine
end and either a bayonet or thread‑in fitting on the tank end. This assembly may
be used in all applications not governed by US‑EPA 2011 regulations.
Quicksilver Branded, Box Point of Sale Packaged.
8 FT. FUEL LINE ASSEMBLY

32-8M0056640
Has double sealed quick connect type fitting on (Super) tank end and no fitting on
engine end. Primer bulb is included in this 8 ft. (2.44 m) assembly.
Fits remote model 40‑60 hp. FourStroke Mercury/Mariner outboards 2008 and
newer. US‑EPA regulated engines and boats may not use this hose.
8 FT. FUEL LINE ASSEMBLY

32-8M0054324
Low Permeation (EPA compliant) hose has standard quick connect type fitting on
engine end and 1/4" NPT threaded fitting on the tank end. A non‑EPA compliant
primer bulb is included in this 8 ft. (2.44 m) assembly.
Fits Force 40 hp. and larger (1993 and Newer), Force 9.9/15/25 hp. (1998) and all
Mercury/Mariner outboards using clip on type disconnect at engine ends and a tank
with threaded fuel pickup fitting. This assembly may be used in all applications not
governed by US‑EPA 2011 regulations.
Quicksilver Branded, Box Point of Sale Packaged.
32-8M0061293
There are no ends on this 8 ft. (2.44 m) fuel line assembly with a non‑EPA
compliant primer bulb. Bulbs will perform at ‑15 Degrees C (5 Degrees F) after 6
weeks of exposure to fuel.
This 5/16 inch (8 mm) I.D. fuel line will adapt to a variety of uses by adding
connectors as desired. US‑EPA regulated boats and engines may not use this
hose assembly.
Mercury Branded
