P. 472
FUEL SYSTEM
FUEL LINE FITTINGS AND COMPONENTS THREADED HOSE BARB
THREADED HOSE BARB MERCURY®/MARINER®/FORCE®
22-8M0125175
For use with 3/8"‑18 (9.5MM). Threads into our portable fuel tanks and will also
work with our water separating filter bracket.
22-8M0086290 .375 inch ID stainless steel fitting for use with both gasoline and diesel fuel.
For use with 3/8" (9.5 mm) I.D. hose and applications requiring a 1/2" NPT thread.
Threads into our portable fuel tanks and will also work with our water separating THREADED HOSE BARB
filter bracket.
A brass fitting for use with both gasoline fuel only. This material should not be used
with diesel fuels.
THREADED HOSE BARB
22-8M0058419
For use with 5/16" (8 mm) I.D. hose and applications requiring a 1/4" NPT thread.
Threads into our portable fuel tanks and will also work with our water separating
filter bracket.
A stainless steel fitting for use with both gasoline and diesel fuel.
22- 89771Q 2 This fitting has a .300 inch ID.
For use with 5/16" (8 mm) I.D. hose and applications requiring a 1/4" NPT thread.
Threads into our portable fuel tanks and will also work with our water separating THREADED HOSE BARB-ENGINE END
filter bracket.
A .250 inch ID brass fitting for use with gasoline fuel only. This material should not
be used with diesel fuels.
Priced individually, sold @ multiples of 2
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
THREADED HOSE BARB
22- 89772Q 1
For use with .3125 In. (8 mm) I.D. hose and applications requiring a .125 In. NPT
thread.
Priced individually, sold @ multiples of 2
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
PIPE PLUG
22- 34982
For use with 3/8" (9.5 mm) I.D. hose and applications requiring a 1/4" NPT thread.
Threads into our portable fuel tanks and will also work with our water separating
filter bracket.
A .375 inch ID brass fitting for use with gasoline fuel only. This material should not
be used with diesel fuels.
22- 32561
1/4" ‑18 NPT (Steel)
Priced individually, sold @ multiples of 2
Quicksilver Product Guide 463
