OPTIMAX MODELS

OPTIMAX MODELS

MAINTENANCE TOOL APPLICATION CHART
OptiMax Model Maintenance Tool Application Chart

Part Number Description 75/90/115 OptiMax DFI 135 thru 175 OptiMax 200 OptiMax Jet Drive 200/225 OptiMax DFI 225/250 Pro EX
DFI OptiMax
44357Q 2 Flushing Devise X X X X
881150K 1 Dual Water Pickup Flash Gearcase Seal Kit X X
91- 37299Q 2 Grease Gun X X X X X
91- 90455 1 Lifting Eye X X X
91- 98234A 2 Transom Drill Fixture X X

MAINTENANCE TOOLS GREASE GUN

FLUSHING ATTACHMENT

91- 37299Q 2
Pistol grip gun. Aids in the lubrication of key areas on the drive and transom.
Allows easy access to grease fittings.
44357Q 2 For use with 8 oz.(227 g) tubes.
Will allow for running at idle speeds. Attaches to the water intakes; provides a Priced individually, sold @ multiples of 4
fresh water connection when flushing the cooling system or operating the engine.
Fits Mercury/Mariner 20 hp. and higher outboards, 9.9/15 hp. FourStroke (323cc) Quicksilver Branded, Clamshell Package Point of Sale Packaged.
Bigfoot outboards, all Model Year 2005 and Newer 8/9.9 hp. Four Stroke OUTBOARD ENGINE LIFTING EYE
outboards, 15 hp. FourStroke (351cc) outboards, all MerCruiser Sterndrives
(except Bravo One Perf. & Blackhawk) and MHP Torque Master gearcases.
Note: 2000 and newer V‑6 outboards and MerCruiser Bravo drives with dual water
pick‑up also require Dual Water Pick‑Up Flush Seal Kit p/n 881150Q 1.
Priced individually, sold @ multiples of 4
OPTIMAX MODELS DUAL WATER PICKUP FLUSH SEAL KIT
Quicksilver Branded, Clamshell Package Point of Sale Packaged.

91- 90455 1
Threads into the flywheel to remove the power head assembly from the driveshaft
housing, or to lift entire engine for removal/installation.
Fits most 2 cycle Mercury/Mariner Outboards from the 30/40 (2 cyl.) on up.

881150K 1
Provides a front water pick‑up seal for gearcases with dual water pick‑ups
Fits 2000 and newer Mercury/Mariner V‑6 outboards with dual water pick‑ups;
and 2000 and newer MerCruiser Bravo One, X, XR & XZ drives with dual water
pick‑ups.
Priced individually, sold @ multiples of 2
Mercury Branded, Clamshell Package Point of Sale Packaged.
