OPTIMAX MODELS
BEARING DRIVER BEARING CUP DRIVER
91- 87120T
91-856875A 1 Installs the forward gear bearing cup.
Installs propeller shaft needle bearing into 3 jaw or 6 jaw forward gear.
BEARING DRIVER
CROSS PIN TOOL
91- 86642
Installation of cross pin.
Outboard
CROSS PIN INSTALLATION TOOL
91-877321A 1
Installs propeller shaft needle bearing into 6 jaw forward gear.
DIAL INDICATOR HOLDING TOOL
91- 86642 2
Cross Pin (T‑Handle) Installation tool. Assists in the assembly/disassembly of the
clutch cross pin.
GUIDE PLATE
91- 89897 OPTIMAX MODELS
Secures the dial indicator to the gear housing when checking backlash.
DRIVESHAFT HOLD TOOL
91- 86943T
Guides the forward gear bearing during installation.
91- 90094
Using to hold bearing nut for driveshaft.
