VERADO L4 AND L6 MODELS

VERADO L4 AND L6 MODELS

MAINTENANCE TOOL APPLICATION CHART DUAL WATER PICKUP FLUSH SEAL KIT

Verado Maintenance Tool Application Chart
Part Number Description 200 thru 400
135/150/175 Verado Verado 4-Stroke
4-Stroke (4 cyl)
(6 cyl)
44357Q 2 Flushing Device X X
881150K 1 Dual Water Pick-Up Flush X X
Gearcase Seal Kit
888462A 1 Data Cable Puller X X
91-889277Q03 Oil Filer Wrench X X 881150K 1
91-892866A01 Oil Drain Funnel X Provides a front water pick‑up seal for gearcases with dual water pick‑ups
91-895343T02 Flywheel Puller / Lifting Ring X X Fits 2000 and newer Mercury/Mariner V‑6 outboards with dual water pick‑ups;
and 2000 and newer MerCruiser Bravo One, X, XR & XZ drives with dual water
90265A 5 Crankcase Oil Pump X X pick‑ups.
91- 98234A 2 Transom Drilling Fixture X X Priced individually, sold @ multiples of 2
EEPV303B(1) Compression Tester with X X Mercury Branded, Clamshell Package Point of Sale Packaged.
Adapter DATA CABLE PULLER
EEPV309A(1) Cylinder Leakage Test X X
(1) Order from Snap-On Tools (800)762-7664

MAINTENANCE TOOLS

FLUSHING ATTACHMENT

888462A 1
Attaches to end of data harness to aid in pulling harness through boat. Prevents
damage to data harness.
OIL FILTER WRENCH

44357Q 2
Will allow for running at idle speeds. Attaches to the water intakes; provides a
fresh water connection when flushing the cooling system or operating the engine.
Fits Mercury/Mariner 20 hp. and higher outboards, 9.9/15 hp. FourStroke (323cc)
Bigfoot outboards, all Model Year 2005 and Newer 8/9.9 hp. Four Stroke
outboards, 15 hp. FourStroke (351cc) outboards, all MerCruiser Sterndrives
(except Bravo One Perf. & Blackhawk) and MHP Torque Master gearcases.
Note: 2000 and newer V‑6 outboards and MerCruiser Bravo drives with dual water
pick‑up also require Dual Water Pick‑Up Flush Seal Kit p/n 881150Q 1.
Priced individually, sold @ multiples of 4
Quicksilver Branded, Clamshell Package Point of Sale Packaged. 91-889277Q03
Metal wrench, requires a .375 in. drive ratchet.
Removes the 896546_ series and 883701_ series production oil filters found on the
early Verado 135‑275 hp. FourStroke outboards.
Quicksilver Branded, Clamshell Package Point of Sale Packaged.

Mercury Service Tool Guide 151 VERADO L4 AND L6 MODELS
