Page 177 - Mercury Service Tool Guide (2020) - 8M0163249
P. 177
SMARTCRAFT / DIGITAL THROTTLE AND SHIFT TOOLS
14 PIN DEPINNING TOOL
91-896352A01
Used to remove pins on 14 pin DTS and non‑DTS harnesses.
BREAK-OUT BOX FOR M CHI
91-898254
Used for DTS installs and trouble shooting. Connects between the command
module and the command module harness. Test harness circuits and the input/
output voltage at the command module.
All DTS installations
