SMARTCRAFT / DIGITAL THROTTLE AND SHIFT TOOLS

SMARTCRAFT / DIGITAL THROTTLE AND SHIFT TOOLS

DATA CABLE PULLER CAN 1 DIAGNOSTIC CABLE

888462A 1 84-892663
Attaches to end of data harness to aid in pulling harness through boat. Prevents CAN 1 diagnostic cable connects into a junction box or male to male adpater cable
damage to data harness. for Command Modulr configuration. Not for use with DDT, cable compatible with
CDS only.
ADAPTER HARNESS
HOSE CLAMP KIT

84-822560T12
Adapts the 2 pin Digital Diagnostic Terminal harness (822560A5) to the flat 4 pin 91-803146A04
connector on the engine. Various clamps and the crimping tool in a convenient plastic tray container. Kit is
Verado 200‑275 Hp originally furnished with 15 each of the 12.8mm,14.0mm, 15.3mm, 16.2mm clamps
PCM 555 Models and 5 each of the 25.6mm and 28.6mm diameter stainless steel clamps.
Aids in the installation of high pressure hose clamps.
ADAPTER HARNESS
SHUNT TOOL

84-825003A 1 TOOLS SMARTCRAFT / DIGITAL THROTTLE AND SHIFT
Data link extension harness (3.05m (10 ft) between 2 pin digital diagnostic terminal 889675A01
harness to the 4 pin connector on the engine. 14 pin.
ADAPTER-10 PIN TACHOMETER / MULTI METER KIT

84-892452T01 91-892647A01
Male to male 10 pin adapter cable. Allows connection between CAN 1 Measures RPM on spark ignition (SI) engines. ohms, amperes, AC and CD
communication cable and Command Module harness in applications where a voltages; records maximums and minimums simultaneously and accurately reads
junction box is used. in high RFI environments.
