CRIMPING TOOL TRANSOM MOUNTED IGNITION KEYSWITCH

91-808696
Crimps the electrical connector to the wire.
DIRECT VOLTAGE ADAPTER
15000A 7
Includes a push‑to‑choke function and a warning horn. Has a 6 ft. (182 cm) cable
length. Has an 8 pin engine connector.
Fits many varying outboards and applications through Model Year 2005 where a
keyswitch with warning horn and choke (enrichner) function is desired. Outboards
require a remote control engine harness be used in conjunction with this switch in
order for it to function. Warning horn feature is not present on all model outboards.
REMOTE SWITCH

91- 89045 1
Direct voltage adapter tool.
AMPERE PROBE TOOL

91- 52024A 1
Use for oil pump testing.
MERCATHODE REFERENCE ELECTRODE TESTER

91-802650 1
All applications.
TRANSOM MOUNTED IGNITION KEYSWITCH

91-8M0135998
Use with a digital multimeter to test the function of Mercathode systems. Senses
an electrical current in the water when testing the Mercathode system.
ELECTRICAL HARDWARE KIT

15000A14
Includes a push‑to‑choke function and a warning horn. Has a 6 ft. (182 cm) cable
length. Has the 14 pin engine connector.
Fits many varying outboards and applications beginning in Model Year 2006 where
a keyswitch with warning horn and choke (enrichner) function is desired. Outboards
require a remote control engine harness be used in conjunction with this switch in
order for it to function. Warning horn feature is not present on all model outboards.

86-813937A 2 ELECTRICAL
Contains a broad selection of the electrical connectors used on Mercury/Mariner/
Force and MerCruiser products.
