ELECTRICAL

IGNITION TIMING TOOL 14 PIN DEPINNING TOOL

91-818812A 1 91-896352A01
Locks the electronic spark trigger ignition system in base timing mode to set the Used to remove pins on 14 pin DTS and non‑DTS harnesses.
initial ignition timing. Also used as a jumper lead for testing various circuits.
Outboard and MerCrusier KEY SWITCH W/ HARNESS - NON DTS 14 PIN
ADAPTER - NON DTS 10 PIN TO 14 PIN

84-896537K02
2 ft. harness (896537A02) with new 14 pin connector for the engine and additional
84-892444T02 connectors that allow easy quick connect solutions to the rigging process. Included
Adapter that allows you to connect engines that have the older 10 pin engine in this kit is also the new 3 position water‑proof high quality keyswitch. (897716)
harness to the newer 14 pin helm harness 2006 and newer Non DTS Outboards from 25 Hp to 250 HP‑ 14 Pin Connectors
MCM/MIE engines that have the 10 pin engine harness. All MCM / MIE engines equiped with 14 pin connectors
TACHOMETER / MULTI METER KIT

91-892647A01
Measures RPM on spark ignition (SI) engines. ohms, amperes, AC and CD
voltages; records maximums and minimums simultaneously and accurately reads
in high RFI environments.
Outboard and MerCruiser
DVA/MULTIMETER

ELECTRICAL Tests the electrical and ignition systems. Consists of a VOA meter with built‑in
91- 99750A 1
direct voltage adapter.
