BRAVO STERNDRIVE

FLUSHING KIT GEARCASE HEIGHT TOOL KIT

91-8M0130705
Engine and gearcase height measurement tool.
Measures engine (gearcase) height in reference to the boat bottom.
All engine gearcase types.
WATER HOSE REPAIR TOOL
91-8M0155826
Seats the Bravo water tube grommet into the gimbal housing to istall the water inlet
849996T 1 housing. Also used for removal and installation of the grommet without replacing
Use for flushing gearcases with low water inlets/pick up. the water tube.
Fits MCM Bravo I Performance & BlackHawk drives For Bravo transoms
Mercury Branded
DUAL WATER PICKUP FLUSH SEAL KIT

881150K 1 BRAVO STERNDRIVE
Provides a front water pick‑up seal for gearcases with dual water pick‑ups
Fits 2000 and newer Mercury/Mariner V‑6 outboards with dual water pick‑ups;
and 2000 and newer MerCruiser Bravo One, X, XR & XZ drives with dual water
pick‑ups.
Priced individually, sold @ multiples of 2
Mercury Branded, Clamshell Package Point of Sale Packaged.
TORCH LAMP

91- 63209
Heats surfaces to aid in the removal and installation of interference fit engine
componenets.
DRILL FIXTURE KIT

91- 43693A 2
Used to assist drilling of the holes for the MerCruiser transom plate mounting bolts.
For MCM 3.0L to 350 Magnum (Alpha One), Bravo One, Two, Three and
Blackhawk models.
