BRAVO STERNDRIVE
END CAP TOOL RETAINER WRENCH TOOL KIT
91-821709T 91-840393A 1
Trim Cylinder End Cap Tool Aids in the installation of the bearing carrier retainer with a heavy‑duty propeller
Allow easy removal of the trim cylinder end caps. Required if tilt limit spacers are shaft installed on the lower unit.
to be installed or if the trim in limit spacer is to be removed to allow additional trim
in range. SEAL INSTALLATION TOOL
DIAL INDICATOR ADAPTER
BRAVO STERNDRIVE
91-8M0059911
91- 83155 Protects the seal when installing the bearing carrier on 10 spline (1.25 in ) propeller
shaft. Part of 840393A1 Propeller shaft Tool Kit.
Dial indicator holding fixture.
RETAINER NUT WRENCH
SHIFT CABLE DRILL BUSHING KIT
91-840393
91-818836A 1 Installs the bearing carrier retainer nut on heavy‑duty propeller shafts.
Aids in replacing a shift cable in bell housing to enlarge hole to .4375 inch for new
cable. ALIGNMENT TOOL
Bravo Drive ‑ S/N 0D542204 and below.
BEARING AND SEAL INSTALL TOOL
91-840965T01
Used to align the engines to the integrated or standard Bravo transom assembly for
sterndrive installation.
91-840385
Installs the needle bearing and oil seals into the bearing carrier.
