DIESEL ENGINE

DATA CABLE PULLER
3.0L DIESEL ENGINE TOOLS
PISTON RING EXPANDER

888462A 1
Attaches to end of data harness to aid in pulling harness through boat. Prevents
damage to data harness.
91- 24697
ALIGNMENT SHAFT Expands piston rings for removal and installation.
FLYWHEEL HOLDER TOOL

91-8M0125730 91- 52344
For MerCruiser drives used with the 4.2L TDI engines Holds and /or turns the flywheel while making engine repairs. Also used to torque
ENGINE MOUNTING FIXTURE the flywheel or the engine coupler.
Use with teeth type flywheel.
DIAL INDICATOR TOOL

DIESEL ENGINE Primary mount assembly. To be used in conjuction with Mount Fixture 22.5 in.(571 Measures distance, movement and runnout. Used for the drive system assembly
91-8M0114831
mm) p/n 8M0114832 and/or Mount Fixture 25.2 in.(640 mm) p/n 8M0114833
91- 58222A 1
For use with all Mercury high speed diesel engines
and engine setup.
ENGINE MOUNTING FIXTURE
DIAL INDICATOR HOLDING TOOL

91-8M0114832
Fixture mount assembly. To be used in conjuction with Primary Mount Assemby p/n 91- 89897
8M0114831 Secures the dial indicator to the gear housing when checking backlash.
For use with all Mercury high speed diesel engines, except the V8 TDI
