DIESEL ENGINE
CRANKSHAFT GEAR PULLER PULLEY PULLER TOOL
91-801333503 91-801763590
Removes the crankshaft gear. Puller removes and the pulley from the crankshaft.
CRANKSHAFT GEAR COVER ASSEMBLY TOOL ALIGNMENT SHAFT TOOL
91-801333504 91-805475A 1
Protects the crankshaft gear and bearings during crankshaft removal and Used to align the engine to the standard Bravo transom assembly for sterndrive
installation. installation.
For MerCruiser drives, except Vazer drives.
FLYWHEEL HOLDER TOOL
PROPELLER NUT TOOL
DIESEL ENGINE Prevents crankshaft rotation during certain service procedures. Used only with the For removal and installation of inner/front propeller nut.
91-895472
91-805457T 1
starter removed.
Bravo Three
BEARING REMOVAL AND INSTALL TOOL
ENGINE MOUNTING FIXTURE
91-801333508
Removes and installs crankshaft bearings and camshaft bearings. 91-807903A 1
Diesel engine mount installation tool fixture.
MerCruiser 2.8 ES (s/n 88010499 and below), D3.0 L, D3.6 L; D4.2 MS / ES (s/n
88020199 and below)
