DIESEL ENGINE

VALVE SPRING COMPRESSOR DUAL WATER PICKUP FLUSH SEAL KIT

91-809494A 1 881150K 1
Removes and installs valve springs. Provides a front water pick‑up seal for gearcases with dual water pick‑ups
Fits 2000 and newer Mercury/Mariner V‑6 outboards with dual water pick‑ups;
ENGINE MOUNTING FIXTURE and 2000 and newer MerCruiser Bravo One, X, XR & XZ drives with dual water
pick‑ups.
Priced individually, sold @ multiples of 2
Mercury Branded, Clamshell Package Point of Sale Packaged.
DIAL INDICATOR TOOL

91-8M0114831
Primary mount assembly. To be used in conjuction with Mount Fixture 22.5 in.(571
mm) p/n 8M0114832 and/or Mount Fixture 25.2 in.(640 mm) p/n 8M0114833
For use with all Mercury high speed diesel engines
ENGINE MOUNTING FIXTURE 91- 58222A 1
Measures distance, movement and runnout. Used for the drive system assembly
and engine setup.
MERCATHODE REFERENCE ELECTRODE TESTER

91-8M0114833
Fixture mount assembly. To be used in conjuction with Primary Mount Assemby p/n DIESEL ENGINE
8M0114831
For use with Mercury high speed V8 TDI diesel engines
91-8M0135998
2.8L I4 / 4.2L I6 DIESEL ENGINE TOOLS Use with a digital multimeter to test the function of Mercathode systems. Senses
an electrical current in the water when testing the Mercathode system.
Includes QSD Engines. GRADUATED TIMING DISK

PISTON RING EXPANDER

91-8M0120214
Sets valve clearance and time, and determines the piston position. Used with the
crankshaft tool (P/N 814827).

91- 24697
Expands piston rings for removal and installation.
