Page 87 - Mercury Service Tool Guide (2020) - 8M0163249
P. 87
TWO STROKE MODELS
BEARING INSTALL DRIVER WEAR SLEEVE DRIVER
91- 13945
Installs reverse gear needle bearing into propeller shaft carrier. 91- 14310T 1
Installs wear sleeve onto driveshaft.
OIL SEAL DRIVER
BEARING PRELOAD TOOL
91- 13949 91- 14311A04
Installs oil seals into water pump base.
Simulates a load on the driveshaft for acurate pinion height and backlash
BEARING RACE DRIVER measurements.
NEEDLE BEARING DRIVER
91- 14308T02
Removes pinion bearing race. 91- 15755T
BEARING INSTALLATION PULLER Installs needle bearings into bearing carriers.
BEARING ADAPTER TOOL
91- 14309T02
Installs pinion bearing into gearcase. 91- 18605A 2
Installs the forwar gear bearing race on a standard gearcase. Presses the revese
gear bearing adapter into the gear housing on a counter‑rotation gearcase.
TWO STROKE MODELS
