MERCURY PROPELLER RIGGING CHART
Pro FourStroke 200 HP ‑ V6 ‑ Freshwater Fish / Runabout / Fish and Ski
Engine RPM Range: 5800 ‑ 6400 Gearcase Ratio 1.85:1
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description Performance Category
13.5 22 3 2300-2600 59-68 48-8M0151245 Enertia Comp Series
13.6 21 3 2500-2800 57-64 48-8M0151243 Enertia Comp Series
13.8 20 3 2750-2950 54-63 48-8M0151241 Enertia Comp Series
14 19 3 2800-3200 51-58 48-8M0151239 Enertia Comp Series
14.3 18 3 2950-3450 47-55 48-8M0151237 Enertia Comp Series
14.5 17 3 3100-3700 45-52 48-8M0151235 Enertia Comp Series
14.7 16 3 3350-4250 41-50 48-8M0151233 Enertia Comp Series
15 15 3 3600-4400 38-47 48-8M0151231 Enertia Comp Series
14.6 23 3 2200-2500 63-71 48-8M0151383 Tempest Plus Elite Series
14.6 21 3 2500-2800 57-64 48-8M0151382 Tempest Plus Elite Series
14.6 19 3 2800-3200 51-58 48-8M0151381 Tempest Plus Elite Series
14.6 17 3 3000-3500 45-52 48-8M0151380 Tempest Plus Elite Series
14 23 3 2200-2500 63-71 48-8M0084497 SpitFire Elite Series
14 21 3 2500-2800 57-64 48-8M0084496 SpitFire Elite Series
14 19 3 2800-3200 51-58 48-8M0084495 SpitFire Elite Series
14 17 3 2200-2500 63-71 48-8M0084494 SpitFire Elite Series
14.3 21 3 2500-2800 57-64 48-832832A45 Black Max Sport Series
14.5 19 3 2800-3200 51-58 48-832830A45 Black Max Sport Series
15 17 3 2500-2800 45-52 48-832828A45 Black Max Sport Series
Verado 200 HP – 4Cyl ‑ Freshwater Fish / Runabout / Fish and Ski
Engine RPM Range: 5800‑6400 Gearcase Ratio: 2.08:1
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description Performance Category
13.4 22 3 2800-3200 51-58 48-8M0151245 Enertia Comp Series
13.6 21 3 2900-3300 49-55 48-8M0151243 Enertia Comp Series
13.8 20 3 3000-3600 46-53 48-8M0151241 Enertia Comp Series
14 19 3 3300-3900 43-50 48-8M0151239 Enertia Comp Series
14.2 18 3 3500-4300 39-47 48-8M0151237 Enertia Comp Series
14.4 17 3 3800-4700 36-44 48-8M0151235 Enertia Comp Series
14.7 16 3 4100-5200 33-41 48-8M0151233 Enertia Comp Series
15 15 3 4400-6000 29-38 48-8M0151231 Enertia Comp Series
14.6 21 3 2900-3300 49-55 48-8M0151382 Tempest Plus Elite Series
14.6 19 3 3300-3900 43-50 48-8M0151381 Tempest Plus Elite Series
14.6 17 3 3800-4700 36-44 48-8M0151380 Tempest Plus Elite Series
14 21 3 2900-3300 49-55 48-8M0084496 SpitFire Elite Series
14 19 3 3300-3900 43-50 48-8M0084495 SpitFire Elite Series
14 17 3 3800-4700 36-44 48-8M0084494 SpitFire Elite Series
14.3 21 3 2900-3300 49-55 48-832832A45 Black Max Sport Series
14.5 19 3 3300-3900 43-50 48-832830A45 Black Max Sport Series
15 17 3 3800-4700 36-44 48-832828A45 Black Max Sport Series
15.3 15 3 4400-6000 29-38 48- 78116A45 Black Max Sport Series
150 HP FourStroke ‑ Freshwater Fish / Runabout / Fish and Ski
Engine RPM Range: 5000‑5800 Gearcase Ratio: 1.92:1
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description Performance Category
13.5 22 3 2100-2600 47-57 48-8M0151245 Enertia Comp Series
13.6 21 3 2200-2800 44-54 48-8M0151243 Enertia Comp Series
13.8 20 3 2300-3000 42-52 48-8M0151241 Enertia Comp Series
14 19 3 2500-3200 39-49 48-8M0151239 Enertia Comp Series
14.3 18 3 2700-3200 35-46 48-8M0151237 Enertia Comp Series
14.5 17 3 2900-4000 32-43 48-8M0151235 Enertia Comp Series
14.8 16 3 3100-4500 29-40 48-8M0151233 Enertia Comp Series
2021 Mercury Propeller Guide 17
