Page 38 - Mercury Propeller Guide (2021) - 8M0174460
P. 38
MERCURY PROPELLER RIGGING CHART
Diameter Pitch No of Blades Boat Weight Boat Speed RH Part Number Propeller Name Performance Category
14 22 3 2700-3200 55-65 48-8M0151270 Fury Comp
14.5 26 4 Up to 2700 65-77 48-8M0151281 Fury 4 Comp
14.5 25 4 2400-2900 62-73 48-8M0151280 Fury 4 Comp
14.5 24 4 2500-3000 60-70 48-8M0151279 Fury 4 Comp
14.5 23 4 2600-3100 58-68 48-8M0151278 Fury 4 Comp
14.6 27 3 Up to 2600 67-80 48-8M0151388 Tempest Elite
14.6 26 3 Up to 2700 65-77 48-8M0151387 Tempest Elite
14.6 25 3 2400-2900 62-73 48-8M0151386 Tempest Elite
14.6 24 3 2500-3000 60-70 48-8M0151385 Tempest Elite
14.6 23 3 2600-3200 57-67 48-8M0151384 Tempest Elite
200 Pro XS ‑ 2 Stroke ‑ Bass
Engine RPM Range: 5250‑5750 Gearcase Ratio: 1.75:1
Diameter Pitch No of Blades Boat Weight Boat Speed RH Part Number Propeller Name Performance Category
14 27 3 Up to 2200 70-78 48-8M0151275 Fury Comp
14 26 3 2100-2300 67-75 48-8M0151274 Fury Comp
14 25 3 2200-2500 64-72 48-8M0151273 Fury Comp
14 24 3 2300-2600 62-68 48-8M0151272 Fury Comp
14 23 3 2400-2700 59-65 48-8M0151271 Fury Comp
14 22 3 2500-2800 57-63 48-8M0151270 Fury Comp
14.5 26 4 2100-2300 67-75 48-8M0151281 Fury 4 Comp
14.5 25 4 2200-2500 64-72 48-8M0151280 Fury 4 Comp
14.5 24 4 2300-2600 62-68 48-8M0151279 Fury 4 Comp
14.5 23 4 2400-3700 60-65 48-8M0151278 Fury 4 Comp
14.6 27 3 Up to 2200 70-78 48-8M0151388 Tempest Elite
14.6 26 3 2100-2300 67-75 48-8M0151387 Tempest Elite
14.6 25 3 2200-2500 64-72 48-8M0151386 Tempest Elite
14.6 24 3 2300-2600 62-68 48-8M0151385 Tempest Elite
14.6 23 3 2400-2700 59-65 48-8M0151384 Tempest Elite
14.6 22 3 2600-2900 56-62 48-8M0151383 Tempest Elite
175 Pro XS ‑ 2 Stroke ‑ Bass
Engine RPM Range: 5500‑6000 Gearcase Ratio: 1.87:1
Diameter Pitch No of Blades Boat Weight Boat Speed RH Part Number Propeller Name Performance Category
14 27 3 Up to 2000 68-76 48-8M0151275 Fury Comp
14 26 3 1900-2100 66-73 48-8M0151274 Fury Comp
14 25 3 1900-2200 63-70 48-8M0151273 Fury Comp
14 24 3 2000-2300 60-67 48-8M0151272 Fury Comp
14 23 3 2100-2400 55-62 48-8M0151271 Fury Comp
14 22 3 2200-2400 48-60 48-8M0151270 Fury Comp
14.5 26 4 1900-2100 66-73 48-8M0151281 Fury 4 Comp
14.5 25 4 1900-2200 63-70 48-8M0151280 Fury 4 Comp
14.5 24 4 2000-2300 60-67 48-8M0151279 Fury 4 Comp
14.5 23 4 2100-2400 55-62 48-8M0151278 Fury 4 Comp
14.6 27 3 Up to 2000 68-76 48-8M0151388 Tempest Elite
14.6 26 3 1900-2100 66-73 48-8M0151387 Tempest Elite
14.6 25 3 1900-2200 63-70 48-8M0151386 Tempest Elite
14.6 24 3 2000-2300 60-67 48-8M0151385 Tempest Elite
14.6 23 3 2200-2400 58-64 48-8M0151384 Tempest Elite
14.6 22 3 2300-2600 55-61 48-8M0151383 Tempest Elite
2021 Mercury Propeller Guide 31
