Page 84 - Mercury Propeller Guide (2021) - 8M0174460
P. 84
MERCURY RACING PROPELLER TYPE
48-889973L48 48-889964L49
15.3 X 33 Pitch LH, SS Lab Finished 15.63 X 25 Pitch RH, SS Lab Finished
48-889972L49 48-889964L48
15.63 X 33 Pitch RH, SS Lab Finished 15.3 X 25 RH, SS Lab Finished
48-889972L48 48-889975L69
15.3 X 33 Pitch RH, SS Lab Finished 15.63 X 24 Pitch LH, SS Lab Finished
48-889971L69 48-889975L68
15.63 X 32 Pitch LH, SS Lab Finished 15.3 X 24 Pitch LH, SS Lab Finished
48-889971L68 48-889974L69
15.3 X 32 Pitch LH, SS Lab Finished 15.63 X 24 Pitch RH, SS Lab Finished
48-889970L69 48-889974L68
15.63 X 32 Pitch RH, SS Lab Finished 15.25 X 24 Pitch RH, SS Lab Finished
48-889970L68 48-889975L49
15.3 X 32 Pitch RH, SS Lab Finished 15.63 X 23 Pitch LH, SS Lab Finished
48-889971L49 48-889975L48
15.63 31 Pitch LH, SS Lab Finished 15.25 X 23 Pitch LH, SS Lab Finished
48-889971L48 48-889974L49
15.25 X 31 LH, SS 5BL Lab Finished. 15.63 X 23 Pitch RH, SS Lab Finished
48-889970L49 48-889974L48
15.63 X 31 Pitch RH, SS Lab Finished 15.25 X 23 Pitch RH, SS Lab Finished
48-889970L48
15.3 X 31 Pitch RH, SS Lab Finished BRAVO THREE XR PRO FINISHED
48-889969L69
15.63 X 30 Pitch LH, SS Lab Finished Designed for 250‑520 horsepower gas and diesel powered sport
48-889969L68 cruisers and performance Bravo Three applications. A large diameter 4
15.3 X 30 Pitch LH, SS Lab Finished blade forward propeller followed by a smaller diameter 3 blade aft
48-889968L69 propeller feature built in cup for incredible handling, improved fuel
economy at cruise and boat control. Intended for the Bravo Three XR
15.63 X 30 RH, SS 5BL Lab Finished. drive and can be used with the Bravo Three and Bravo Three X drives.
48-889968L68 The Pro Finish provides a performance leading edge, consistent cup
15.3 X 30 RH, SS Lab Finished heights, zero balanced for minimal vibration and durable high luster
48-889969L49 finish.
15.63 X 29 Pitch LH, SS Lab Finished As a general rule the odd pitch numbered Bravo Three XR propellers
run similar engine RPM to the next higher pitch even numbered Bravo
48-889969L48 Three propellers. For example, the Bravo Three XR 27 pitch matches
15.3 X 29 Pitch LH, SS Lab Finished the RPM of a Bravo Three 28 pitch with satin finish.
48-889968L49
15.63 X 29 Pitch RH, SS Lab Finished BRAVO THREE XR PRO FINISHED PROPELLER
48-889968L48
15.3 X 29 Pitch RH, SS Lab Finished
48-889967L69
15.63 X 28 Pitch LH, SS Lab Finished
48-889967L68
15.3 X 28 Pitch LH, SS Lab Finished
48-889966L69
15.63 X 28 Pitch RH, SS Lab Finished
48-889966L68
15.3 X 28 Pitch RH, SS Lab Finished
48-889967L49 48-842945L80
15.63 X 27 Pitch LH, SS Lab Finished 15.5 x 28 Pitch LH SS 4 BL High Gloss ‑ Front
48-889967L48 48-842946L80
15.3 X 27 Pitch LH, SS Lab Finished 14.5 x 28 Pitch RH, SS 3 BL High Gloss ‑ Rear
48-889966L49 48-8M0125747
15.63 X 27 Pitch RH, SS Lab Finished 15.5 x 27.5 Pitch LH, SS 4 BL High Polished ‑ Forward
48-889966L48 48-8M0125746
15.3 X 27 Pitch RH, SS Lab Finished 14.5 x 27.5 Pitch RH, SS 3 BL High Gloss ‑ Rear
48-889965L69 48-842945L70
15.63 X 26 Pitch LH, SS Lab Finished 15.5 x 27 Pitch LH, SS 4 BL High Gloss ‑ Front
48-889965L68 48-842946L70
15.3 X 26 Pitch LH, SS Lab Finished 14.5 x 27 Pitch RH, SS 3 BL High Gloss ‑ Rear
48-889964L69 48-842943L80
15.63 X 26 Pitch RH, SS Lab Finished 15.8 X 26 Pitch LH, SS 4 BL High Gloss ‑ Front
48-889964L68 48-842944L80
15.3 X 26 Pitch RH, SS Lab Finished 14.8 X 26 Pitch RH, SS 3 BL High Gloss ‑ Rear
48-889965L49 48-8M0125745
15.63 X 25 Pitch LH, SS Lab Finished 15.8 x 25.5 Pitch LH, SS 4 BL High Polished ‑ Forward
48-889965L48
15.3 X 25 LH, SS Lab Finished
