MERCURY RACING PROPELLER TYPE
48-8M0160808 CNC CLEAVER 5 BLADE 12 DEGREE RAKE LAB
15.25 x 32 Pitch RH 18 Rake
48-8M0160807 FINISHED
15.25 x 32 Pitch LH 18 Rake
48-8M0160852 Varying horsepower ratings available depending on application, from
14.75 x 33 Pitch RH 18 Rake 600 hp up to 1800 hp
822974 Six and 8M drive bushing
48-8M0160853 822975 Retaining ring
14.75 x 33 Pitch LH 18 Rake 11‑826135 Nylon Insert, 8M0035647 Brass, 11‑39817 Washer and nuts
48-8M0159338 for SSM Six and M8
15.00 x 33 Pitch RH 18 Rake For use with Mercury Racing IIIA, IV, V, NXT (NXT1 requires hub kit
48-8M0159339 8M8022263 ‑ sold separate), VI SSM and M8 Sterndrive. The CNC Pro
Finish propellers have a 26 Spline hub with 1.75/1.88 inch
15.00 x 33 Pitch LH 18 Rake (44.5/47.7mm) O.D. propeller shaft and 6 inch (152mm) hub length. The
48-8M0160854 15 degree rake propellers are designed specifically for step Vee hulls,
15.25 x 33 Pitch RH 18 Rake diameters from 15 inch to 18 inch and pitch from 26 inch to 40 inch
48-8M0160855 (custom order 41 and 42 inch pitch,14.5" diameters and limited 13
15.25 x 33 Pitch LH 18 Rake degree rake available ‑ contact Mercury Racing).
If moving from the old style 5 blade Cleaver to the new style 5 blade
48-8M0160834 CNC Cleaver generally move up 2 inch of pitch; example if old style was
14.75 x 34 Pitch RH 18 Rake 17 x 33 move to 17 x 35 CNC Cleaver.
48-8M0160835
14.75 x 34 Pitch LH 18 Rake As a general rule for every 1 inch of pitch change, the effect will typically
48-8M0159340 be 150 RPM change. For every .50 inch of diameter change, the effect
will typically be 150 RPM change.
15.00 x 34 Pitch RH 18 Rake
48-8M0159341 For a complete listing of part numbers see Mercury Racing Propeller
15.00 x 34 Pitch LH 18 Rake chart section.
48-8M0160836
15.25 x 34 Pitch RH 18 Rake CNC CLEAVER 5 BLADE 15 DEGREE RAKE LAB
48-8M0160837
15.25 x 34 Pitch LH 18 Rake FINISHED
48-8M0160828
14.75 x 35 Pitch RH 18 Rake Varying horsepower ratings available depending on application, from
48-8M0160829 600 hp up to 1800 hp
822974 Six and 8M drive bushing
14.75 x 35 Pitch LH 18 Rake 822975 Retaining ring
48-8M0160830 11‑826135 Nylon Insert, 8M0035647 Brass, 11‑39817 Washer and nuts
15.00 x 35 Pitch RH 18 Rake for SSM Six and M8
48-8M0160831 For use with Mercury Racing IIIA, IV, V, NXT (NXT1 requires hub kit
15.00 x 35 Pitch LH 18 Rake 8M8022263 ‑ sold separate), VI SSM and M8 Sterndrive. The CNC Pro
Finish propellers have a 26 Spline hub with 1.75/1.88 inch
48-8M0160832 (44.5/47.7mm) O.D. propeller shaft and 6 inch (152mm) hub length. The
15.25 x 35 Pitch RH 18 Rake 15 degree rake propellers are designed specifically for step Vee hulls,
48-8M0160833 diameters from 15 inch to 18 inch and pitch from 26 inch to 40 inch
15.25 x 35 Pitch LH 18 Rake (custom order 41 and 42 inch pitch,14.5" diameters and limited 13
48-8M0159974 degree rake available ‑ contact Mercury Racing).
If moving from the old style 5 blade Cleaver to the new style 5 blade
14.75 x 36 Pitch RH 18 Rake CNC Cleaver generally move up 2 inch of pitch; example if old style was
48-8M0159975 17 x 33 move to 17 x 35 CNC Cleaver.
14.75 x 36 Pitch LH 18 Rake
48-8M0159976 As a general rule for every 1 inch of pitch change, the effect will typically
15.00 x 36 Pitch RH 18 Rake be 150 RPM change. For every .50 inch of diameter change, the effect
will typically be 150 RPM change.
48-8M0159977
15.00 x 36 Pitch LH 18 Rake For a complete listing of part numbers see Mercury Racing Propeller
48-8M0159978 chart section.
15.25 x 36 Pitch RH 18 Rake
48-8M0159979
15.25 x 36 Pitch LH 18 Rake
48-8M0160042
14.75 x 37 Pitch RH 18 Rake
48-8M0160041
14.75 x 37 Pitch LH 18 Rake
48-8M0160044
15.00 x 37 Pitch RH 18 Rake
48-8M0160043
15.00 x 37 Pitch LH 18 Rake
48-8M0160046
15.25 x 37 Pitch RH 18 Rake
48-8M0160045
15.25 x 37 Pitch LH 18 Rake
2021 Mercury Propeller Guide 81
