P. 87
MERCURY RACING PROPELLER TYPE
48-8M0163492 48-8M0160105
15.25 x 38 Pitch RH 15 Rake 14.75 x 27 Pitch LH 18 Rake
48-8M0163493 48-8M0160112
15.25 x 38 Pitch LH 15 Rake 15.00 x 27 Pitch RH 18 Rake
48-8M0163514 48-8M0160111
14.75 x 39 Pitch RH 15 Rake 15.00 x 27 Pitch LH 18 Rake
48-8M0163513 48-8M0160114
14.75 x 39 Pitch LH 15 Rake 15.25 x 27 Pitch LH 18 Rake
48-8M0163516 48-8M0160113
15.00 x 39 Pitch RH 15 Rake 15.25 x 27 Pitch LH 18 Rake
48-8M0163515 48-8M0160484
15.00 x 39 Pitch LH 15 Rake 14.75 x 28 Pitch RH 18 Rake
48-8M0163518 48-8M0160483
15.25 x 39 Pitch RH 15 Rake 14.75 x 28 Pitch LH 18 Rake
48-8M0163517 48-8M0160486
15.25 x 39 Pitch LH 15 Rake 15.00 x 28 Pitch RH 18 Rake
48-8M0163522 48-8M0160485
14.75 x 40 Pitch RH 15 Rake 15.00 x 28 Pitch LH 18 Rake
48-8M0163521 48-8M0160488
14.75 x 40 Pitch LH 15 Rake 15.25 x 28 Pitch RH 18 Rake
48-8M0163524 48-8M0160487
15.00 x 40 Pitch RH 15 Rake 15.25 x 28 Pitch LH 18 Rake
48-8M0163523 48-8M0160582
15.00 x 40 Pitch LH 15 Rake 14.75 x 29 Pitch RH 18 Rake
48-8M0163526 48-8M0160581
15.25 x 40 Pitch RH 15 Rake 14.75 x 29 Pitch LH 18 Rake
48-8M0163525 48-8M0160584
15.25 x 40 Pitch LH 15 Rake 15.00 x 29 Pitch RH 18 Rake
48-8M0160583
CNC OUTBOARD CLEAVER 500 HP 18 DEGREE 15.00 x 29 Pitch LH 18 Rake
RAKE 48-8M0160586
15.25 x 29 Pitch RH 18 Rake
48-8M0160585
•The Lab Finished CNC Outboard Cleaver is designed to be the most
efficient propeller for high speed applications 15.25 x 29 Pitch LH 18 Rake
•As opposed to a standard propeller, the CNC machining process offers 48-8M0160652
superior precision and replicability for all dimensions of the propeller 14.75 x 30 Pitch RH 18 Rake
•18 degree rake is applicable for high speed vee bottoms and some 48-8M0160653
catamarans that require additional bow lift 14.75 x 30 Pitch LH 18 Rake
•Broched splines for 1.25 inch prop shaft, designed for 450R outboard
•Additional dimensions are available for custom order 48-8M0160654
15.00 x 30 Pitch RH 18 Rake
LAB FINISHED OUTBOARD CNC CLEAVER 48-8M0160655
15.00 x 30 Pitch LH 18 Rake
48-8M0160656
15.25 x 30 Pitch RH 18 Rake
48-8M0160657
15.25 x 30 Pitch LH 18 Rake
48-8M0160738
14.75 x 31 Pitch RH 18 Rake
48-8M0160737
14.75 x 31 Pitch LH 18 Rake
48-8M0160740
15.00 x 31 Pitch RH 18 Rake
48-8M0159956
48-8M0160739
14.75 x 26 Pitch RH 18 Rake 15.00 x 31 Pitch LH 18 Rake
48-8M0159955
48-8M0160742
14.75 x 26 Pitch LH 18 Rake 15.25 x 31 Pitch RH 18 Rake
48-8M0154970 48-8M0160741
15.00 x 26 Pitch RH 18 Rake 15.25 x 31 Pitch LH 18 Rake
48-8M0154969
48-8M0160804
15.00 x 26 Pitch LH 18 Rake 14.75 x 32 Pitch RH 18 Rake
48-8M0160052 48-8M0160803
15.25 x 26 Pitch RH 18 Rake 14.75 x 32 Pitch LH 18 Rake
48-8M0160051
48-8M0160806
15.25 x 26 Pitch LH 18 Rake 15.00 x 32 Pitch RH 18 Rake
48-8M0160106
14.75 x 27 Pitch RH 18 Rake 48-8M0160805
15.00 x 32 Pitch LH 18 Rake
