Page 285 - QUICKSILVER MARINE PARTS GUIDE (2019)

TILT/TRIM MOTORS

TILT/TRIM MOTOR TILT/TRIM MOTOR
TILT/TRIM MOTORS

8M6007566
Tilt / Trim Motor: For Yamaha: 12‑Volt.
Used on 2005‑08 Yamaha F75TLR, F90TJR, F90TLR, F90TXR 4‑Stroke power tilt
8M6007563 & trim assembly.
Tilt / Trim Motor: For Yamaha: 12‑Volt. 2‑wire, 3‑bolt mount. J & N P/N: 430-22118
Used on 2002‑09 Yamaha F200, F225, F250, LF200, LF225, LF250, LZ250, Yamaha Motor Corp. P/N: 6D8-43880-00-00, 6D8-43880-01-00,
LZ300, Z250, Z300 engines. 6D8-43880-09-00
J & N P/N: 430-22098
Lester P/N: 10865 TILT/TRIM MOTOR
Yamaha Motor Corp. P/N: 60V-43880-00-00, 69J-43880-00-00
TILT/TRIM MOTOR

8M6007567
Tilt / Trim Motor: For Yamaha: 12‑Volt. 2‑wire, ring terminal ends, 4‑bolt mount.
Used on 1985‑92 Yamaha 40‑50HP engines.
J & N P/N: 430-22059
Lester P/N: 10836
8M6007564 Yamaha Motor Corp. P/N: 6H5-43880-01-00, 6H5-43880-02-00
Tilt / Trim Motor: For Yamaha: 12‑Volt. 2‑wire, 3‑bolt mount. TILT/TRIM MOTOR
Used on 2005‑09 Yamaha F50 and F60.
J & N P/N: 430-22077
Lester P/N: 10860
Yamaha Motor Corp. P/N: 6C5-43880-00-00, 6C5-43880-01-00
TILT/TRIM MOTOR

8M6007568
Tilt / Trim Motor: For Yamaha: 12‑Volt. 3‑wire. Mounting flange measures 68.3mm,
armature shaft blade is 4mm thick.
Used on 1985‑86 Yamaha 50‑200HP engines.
J & N P/N: 430-22082
Lester P/N: 10835
Yamaha Motor Corp. P/N: 688-43880-10-00, 688-43880-11-00,
6E5-43880-01-00, 6E5-43880-02-00
8M6007565
Tilt / Trim Motor: For Yamaha: 12‑Volt. 2‑wire, 4‑bolt mount. Late model 4‑Stroke
engines.
Used on 2003‑04 Yamaha F75, F90 and 1999‑03 F80, F100.
J & N P/N: 430-22066
Lester P/N: 10862
Yamaha Motor Corp. P/N: 67F-43880-00-00

280
