TILT/TRIM MOTORS

TILT/TRIM MOTOR TILT/TRIM MOTOR TILT/TRIM MOTORS

8M6007569
Tilt / Trim Motor: For Yamaha: 12‑Volt. 2‑wire, ring terminal ends.
Used on 1986‑95 115‑200HP Yamaha engines. 8M6007572
J & N P/N: 430-22029 Tilt / Trim Motor: For Yamaha: 12‑Volt. 2‑wire, ring terminal ends.
Lester P/N: 10824, 10849 Used on 1992‑95 Yamaha 50‑90HP engines.
Yamaha Motor Corp. P/N: 6G5-43880-02-00
J & N P/N: 430-22028
TILT/TRIM MOTOR Lester P/N: 10830
Yamaha Motor Corp. P/N: 6H1-43880-02-00
TILT/TRIM MOTOR

8M6007570
Tilt / Trim Motor: For Yamaha: 12‑Volt. 2‑wire, leads have butt connectors. 68.3mm
mounting flange diameter. OE was 3‑wire ‑ replacement is 2‑wire. 8M6007573
Used on 1987‑91 Yamaha 115‑225HP engines. Tilt / Trim Motor: For Yamaha: 12‑Volt. 2‑wire, ring terminal ends, 3‑bolt mount. For
J & N P/N: 430-22150 longer shaft, see 8M6007574.
Lester P/N: 10825 Used on 1995‑03 Yamaha 40‑100HP engines.
Yamaha Motor Corp. P/N: 6G5-43880-00-00, 6G5-43880-01-00 J & N P/N: 430-22048
Lester P/N: 10833
TILT/TRIM MOTOR Yamaha Motor Corp. P/N: 62X-43880-00-00, 62X-43880-01-00,
62X-43880-09-00
TILT/TRIM MOTOR

8M6007571
Tilt / Trim Motor: For Yamaha: 12‑Volt. 3‑wire. Mounting flange measures 68.3mm,
armature shaft blade is 4mm thick.
Used on 1897‑91 Yamaha 50‑115HP engines.
J & N P/N: 430-22146
Lester P/N: 10832, 10848 8M6007574
Yamaha Motor Corp. P/N: 6H1-43880-00-00 Tilt / Trim Motor: For Yamaha: 12‑Volt. This is the same as the 8M6007573 except
having a 1.5 inch longer shaft from the seal to the flat shaft. Used on 4‑Stroke
applications.
Used on 1995‑03 Yamaha 40‑100HP engines.
J & N P/N: 430-22090
Lester P/N: 10834
Yamaha Motor Corp. P/N: 62Y-43880-01-00, 62Y-43880-02-00,
69W-43880-00-00, 69W-43880-01-00,
69W-43880-09-00, CS3-43880-00-00
