Helm Architecture Diagrams: Single Helm
1 - 14‑pin data harness (to starboard engine) 14 - Blue ERC connector (CAN P)
2 - 14‑pin data harness (to port engine) 15 - Warning horn
3 - CAN X terminators 16 - CAN H adapter (orange)
4 - CAN H terminator 17 - Joystick
5 - Gauge power relay 18 - Electric steering helm
6 - Dual‑engine, single‑helm harness 19 - CAN P adapter (blue)
7 - Accessory power 20 - Dual‑engine ERC
8 - Junction box 21 - GPS/IMU assembly
9 - Ignition key switches 22 - Diagnostic port
10 - Lanyard switch diode pack 23 - VesselView Link
11 - Lanyard stop switch 24 - VesselView (or equivalent MFD)
12 - Brown ERC connector (port) 25 - NMEA® 2000 network
13 - Green ERC connector (starboard)
