Helm Architecture Diagrams: Single Helm
1 - 14‑pin data harness (to starboard engine) 11 - Ignition key switches
2 - 14‑pin data harness (to center engine) 12 - Lanyard switch diode pack
3 - 14‑pin data harness (to port engine) 13 - Lanyard stop switch
4 - CAN X terminators 14 - Gray ERC connector (center)
5 - CAN H terminator 15 - Brown ERC connector (port)
6 - Gauge power relay 16 - Green ERC connector (starboard)
7 - Triple‑engine, single‑helm harness 17 - Blue ERC connector (CAN P)
8 - Accessory power 18 - Warning horn
9 - Junction box 19 - Triple‑engine ERC (dual console)
10 - Diagnostic port
