Laser Marking SMARKY

metalworking

CLASS 1 PRECISION MARKING

SMARKY 10W Air DPS is our best selling laser marker system (Nd:YV04 ) which
works on any surface of metal and almost all industrial hard plastics.

The system consists of two parts: resonator unit-scanner head and power
supply box with control. A 3 m optical bre and signal cable allow the power
supply box to operate laser which can be piloted by Windows® 10® PC.

SMARKY laser machine is proposed in two version: class I equiped with a
suitable working area protection. In the version OEM, class IV, and / or with TECHNICAL SPECIFICATION
motorized X axis. Output power 10W @ 10KHz
• Control : PC Windows with PCI or USB card, RS232 Software Sisma Laser Wave lenght 1064nm
M2
≤1.8
Controller Max. marking 5000 mm/s
• Interfaces : PLC, data network (ethernet), I/O digital, axis control, other Power supply 220 V±15% 50/60 Hz 1 ph
auxiliary devices. Absorbed power 550 W
• Software : Developed by Sisma to set data or images to be marked and Aiming beam RED DIODE LASER
manages laser and all connected devices files can be imported in : SVG, BMP, Marking area 430 X 340 X 117h mm
JPG, HTML, PLT. Dimensions 520 x 600 x 620h mm
Net weight 94 Kgs

Laser Engraving Big Smark BSS 3D

CNC MARKER & ENGRAVING FOR MOULD & DIE INDUSTRY

Automatic laser system for marking and engraving hard plastic and metal
materials. Powered with German made laser source, Japan made electronics
and italian ingenuity, the high quality markergives the possibility to mark up to
180 x 180 mm area.

Specic for 2D and 3D deep engraving on moulds, matrices, punches and
electrodes through movement of the laser source on a portal with 3 axis with a
stroke of 350 mm. The centering is done through an high resolution ultra
compact camera; working cycles, positioning and programming are managed
with a notebook or fixed PC through the master SLC software.

Features:
• Control : PC Windows with PCI board, RS232 software SLC
• Interface : PLC, data network (ethernet), digital I/O
• Software : SLC software for files management marking parameters defining.
Accepted extensions SVG, BMP, JPG, HTML, PLT.
TECHNICAL SPECIFICATION
Output power 20W 40W
Wave lenght 1064nm
Focals F100, F160, F254 mm
Power supply 220V +/- 15% 50/60 Hz lph
Working area 595 x 495 x 800h mm
Cooling system air
Dimensions 640 x 787 x 800h mm
Weight 144 Kgs

For further information, scan the following QR code:
You will be redirected to our website page

www.lfc.co.id 047
