Laser Welding Machine With Movable Head SWA

Sisma oers laser welding systems for mould maintenance and repair, with
and without ller material. The best-sellingSisma SWA 150 with resonator is
metalworking
perfect for high-precision operation especially on larger surface.
The laser source is properly shielded for improved safety, while stable tempe-
rature can be maintained by watercooling radiator system, especially when
you have a long working session on a daily basis.

Works by utilizing Fiber Ytterbium (Yag), Sisma laser beam source emit light
with wavelength of 1064µm (10x smaller diameter compared to Co2 laser).
The laser parameters to set the waveform, diameter of welding spot and rota-
ting spindle X, Y and Z axis can be managed through touch screen.

Tech Specication Also available with 300 Watt laser!
MODEL SWA 150R SWA 150
Average power 150 W 150 W
Peak power 10.5 KW 10.5 KW
Pulse energy 70 J 70 J
Pulse frequency 0-50 Hz
Pulse duration 0.3 - 25ms
Spot diameter 0.2-2mm 0.1 optional
Laser beam transport Direct Fiber-coupled
Focusing optics 120mm
Vision system* Leica binocular
Moving speed 0-20mm/s
X axis stroke 300mm
Y axis stroke 150mm
Z axis stroke 500mm
Cooling air
Power supply 230V 50/60Hz 1ph-1Kw
Alimentazione elettrica e 400V/50/60 Hz 3 ph-3.5 Kw
Dimensions wxlxh 1950x1000x1610 mm
Net weight 270 Kg

*Vision system can also be ordered with digital microscope for convenient imaging quality on bigger screen
