Solid Carbide drill
metalworking

Die Schn ittwerte für alle Werkzeug e
entnehmen Sie bitte unsere m
separaten Zerspan ungshandbuch .
You will find the cutting conditions
for all tools in our separate cu tting
manual.
Per i pa rametri di lavorazione per
tutti gli utensili richie dete il nostr o
manuale tecnico.

Standard DIN 6539 DIN 338
Type N N N N
Depth of drilling 3xd 3xd 5xd 5xd
Coolant supply
Coating ALUNI T ® ALUNI T ®
Lip angle 118˚ 118˚ 118˚ 118˚
ø mm 0,5–20 0,5–14 1–16 1–16
Code 6146 6147 6156 6157
Page 070 070 072 072
Suitable for
Stähle < 400 N/mm 2
S teels < 400 N/mm 2
Acciai < 400 N/mm 2
Stähle < 850 N/mm 2
S teels < 850 N/mm 2
<850 N/mm 2 Acciai < 850 N/mm 2
Stähle < 1.100 N/mm 2
S teels < 1.100 N/mm 2
< 1100 N/mm 2 Acciai < 1.100 N/mm 2
Stähle < 1.300 N/mm 2
S teels < 1.300 N/mm 2
<1300 N/mm 2 Acciai < 1.300 N/mm 2
Stähle > 45 HRC
S teels > 45 HRC
Acciai > 45 HRC
>45 HRC
R ostfreie Stähle < 850 N/mm 2
Stainless s teels < 850 N/mm 2
Acciai inossidabili < 850 N/mm 2
R ostfreie Stähle > 850 N/mm 2
Stainless s teels > 850 N/mm 2
Acciai inossidabili > 850 N/mm 2
Grauguss, Temperguss
Cast iron, malleable cast iron
Ghisa grigia, ghisa malleabile
Titan- und Titanlegierung
Titanium and titanium all oys
Titanio e leghe di Titanio
Kupfer, Messing
Coppe r, brass
R ame, ot tone
Aluminium
Aluminium
Alluminio
Kunststoe
Plastics
Materie plastiche

Ideal / Ideal / Ideale Geeignet / S uitable / Adatte
