Solid Carbide drill Milling Cutter
metalworking

Die Schn ittwerte für alle Werkzeug e
entnehmen Sie bitte unsere m
separaten Zerspan ungshandbuch .
You will find the cutting conditions
for all tools in our separate cu tting
manual.
Per i pa rametri di lavorazione per
tutti gli utensili richie dete il nostr o
manuale tecnico.
Inox Inox Inox Inox Inox Inox
Standard WN DIN 6527L
Type N N N N N N
Length XL-freiges tellt XL-freiges tellt XL-freiges tellt XL-freiges tellt lang-freiges tellt lang-freiges tellt
No. of flutes 4 4 4 4 4 3-4
Head type

Spiral angle 39-42° 39-42° 39-42° 39-42° 39-42° 39-42°
Shank type DIN 6535-HA DIN 6535-HB DIN 6535-HA DIN 6535-HB DIN 6535-HA DIN 6535-HA
Coolant supply
Coating ULTRADU R ULTRADU R ALUNI T-S ® ALUNI T-S ® ULTRADU R ALUNI T-S ®
ø mm 5-20 5-20 5-20 5-20 5-16 2-20
Code 8267 8767 7267 7767 8647 6547
Page 122 122 123 123 124 125
Suitable for
Stähle < 400 N/mm 2
S teels < 400 N/mm 2
Acciai < 400 N/mm 2
Stähle < 850 N/mm 2
S teels < 850 N/mm 2
<850 N/mm 2 Acciai < 850 N/mm 2
Stähle < 1.100 N/mm 2
S teels < 1.100 N/mm 2
<1100 N/mm 2 Acciai < 1.100 N/mm 2
Stähle < 1.300 N/mm 2
S teels < 1.300 N/mm 2
<1300 N/mm 2 Acciai < 1.300 N/mm 2
Stähle > 45 HRC
S teels > 45 HRC
Acciai > 45 HRC
>45 HRC
R ostfreie Stähle < 850 N/mm 2
Stainless s teels < 850 N/mm 2
Acciai inossidabili < 850 N/mm 2
R ostfreie Stähle > 850 N/mm 2
Stainless s teels > 850 N/mm 2
Acciai inossidabili > 850 N/mm 2
Grauguss, Temperguss
Cast iron, malleable cast iron
Ghisa grigia, ghisa malleabile
Titan- und Titanlegierung
Titanium and titanium all oys
Titanio e leghe di Titanio
Kupfer, Messing
Coppe r, brass
R ame, ot tone
Aluminium
Aluminium
Alluminio
Kunststoe
Plastics (1) (1) (1) (1) (1) (1)
Materie plastiche
(1) GFK: glas fase r-verstärk te Kunststoe | GRP: glass-fibre rein forced plastics l FRP: plastica rin forzata con fibra di vetro
Ideal / Ideal / Ideale Geeignet / S uitable / Adatte
