HSS Drill

Die Schn ittwerte für alle Werkzeug e
metalworking
entnehmen Sie bitte unsere m
separaten Zerspan ungshandbuch .
You will find the cutting conditions
for all tools in our separate cu tting
manual.
Per i pa rametri di lavorazione per
tutti gli utensili richie dete il nostr o
manuale tecnico.

Standard DIN 338 WN DIN 340
Type Forte Forte H RN RN
Depth of drilling 8xd 8xd 3xd 10xd 10xd
Cutting material HSS-Co5 HSS-Co5 HSS-Co5 HSS HSS-Co5
Coating ALUNI T ®
Lip angle 130° 130° 135° 118° 118°
Special point shape AC AC C AC AC
ø mm 1-13 1-13 2-13 0,5-16 1-12
Code 611 627 638 501 503
Page 240 240 242 243 244
Suitable for
Stähle < 400 N/mm 2
S teels < 400 N/mm 2
Acciai < 400 N/mm 2
Stähle < 850 N/mm 2
S teels < 850 N/mm 2
Acciai < 850 N/mm 2
<850 N/mm 2
Stähle < 1.100 N/mm 2
S teels < 1.100 N/mm 2
<1100 N/mm 2 Acciai < 1.100 N/mm 2
Stähle < 1.300 N/mm 2
S teels < 1.300 N/mm 2
< 1300 N/mm 2 Acciai < 1.300 N/mm 2
Stähle > 45 HRC
S teels > 45 HRC
>45 HRC Acciai > 45 HRC
R ostfreie Stähle < 850 N/mm 2
Stainless s teels < 850 N/mm 2
Acciai inossidabili < 850 N/mm 2
R ostfreie Stähle > 850 N/mm 2
Stainless s teels > 850 N/mm 2
Acciai inossidabili > 850 N/mm 2
Grauguss, Temperguss
Cast iron, malleable cast iron
Ghisa grigia, ghisa malleabile
Titan- und Titanlegierung
Titanium and titanium all oys
Titanio e leghe di Titanio
Kupfer, Messing
Coppe r, brass
R ame, ot tone
Aluminium
Aluminium
Alluminio
Kunststoe
Plastics
Materie plastiche
