COMBI-mag

Multi-Function Tools
metalworking

Direct Spotting Countersinking Drilling Longitudinal
Chamfer Chamfer

1 COMBI-mag operatious =
5 operacioues
COBALT

HSS-E

α 90º

D h7 L Red’X
inch mm ±1 +1 T* 007
3 50 6 0.3 € 15.50
1/8” 3.17 50 6 0.3 15.50
4 52 8 0.4 16.00
3/16” 4.76 60 9 0.5 16.50
5 60 10 0.5 16.50
6 66 12 0.6 19.50 α 90º 6 pieces
1/4” 6.35 66 12 0.6 20.50
5/16” 7.93 79 14 0.8 22.75 Type Composition
8 79 14 0.8 22.75
3/8” 9.52 89 16 1 26.00 DUO-mag 019 ø 3 - 4 - 6
10 89 16 1 27.00 8 - 10 -12
12 102 18 1.2 35.00 DUO-mag 0919 ø 3 - 4 - 6
1/2” 12.7 102 19 1.3 37.00 8 - 10 - 12
14 115 21 1.4 49.50 COMBI-mag 007 ø 4 - 5 - 6
5/8” 15.87 115 24 1.6 51.50 8 - 10 - 12
16 115 24 1.6 51.50
*T = 0.1 x D : Web thickness

Micro-NC = magafor standard α 90º

D D2 L Red’X
+ 0.01 h5 ±1 +1 T* 007
0.3 3 39 0.9 41.00 € 46.00
0.6 3 39 1.8 32.00 36.00 CARBIDE METAL DURO
0.9 3 39 2.7 32.00 36.00
1.2 3 39 3.6 32.00 36.00
1.5 3 39 4.5 32.00 36.00
2.0 3 39 6.0 32.00 36.00
2.5 3 39 7.5 32.00 36.00
