STANDARD SERIES DOUBLE CLAMP STANDARD SERIES DOUBLE CLAMP
STEEL BOLTS 316 STAINLESS STEEL BOLTS

Part No GROUP SIZE Part No GROUP SIZE
CF1-B CF1 SCF1-B CF1
CF2-B CF2 SCF2-B CF2
CF3-B CF3 SCF3-B CF3
CF4-B CF4 SCF4-B CF4
CF5-B CF5 SCF5-B CF5

STANDARD SERIES DOUBLE CLAMP STANDARD SERIES DOUBLE CLAMP

STEEL BOTTOM PLATE 316 STAINLESS STEEL BOTTOM
PLATE

Part No GROUP SIZE Part No GROUP SIZE
CF1-BP CF1 SCF1-BP CF1
CF2-BP CF2 SCF2-BP CF2
CF3-BP CF3 SCF3-BP CF3
CF4-BP CF4 SCF4-BP CF4
CF5-BP CF5 SCF5-BP CF5

STANDARD SERIES DOUBLE CLAMP STANDARD SERIES DOUBLE CLAMP
STEEL TOP PLATE 316 STAINLESS STEEL TOP PLATE

Part No GROUP SIZE Part No GROUP SIZE
CF1-TP CF1 SCF1-TP CF1
CF2-TP CF2 SCF2-TP CF2
CF3-TP CF3 SCF3-TP CF3
CF4-TP CF4 SCF4-TP CF4
CF5-TP CF5 SCF5-TP CF5

H9
