140 SERIES

CVF

STEEL 140 SERIES WATER BLAST Quick couplings upon request and subjected to minimum quantities.
Nickel-palted product  add 011 at the end of the reference.

• Nickel Plated Carbon Steel
• Free flow, No Poppet Valves MALE (CARBON ST.)
• High Pressure Ratings
• For use with water blasters DN ØA CH1 C ØF L REF.
06 ¼” BSP 19 25 14,10 45,10 140.11001AB 700 Bar
Part No Body Description Connection Working 10 ⅜” BSP 22 28 18,90 48,50 140.11002AC 600 Bar
Size (“) Pressure
(Bar) 13 ½” BSP 27 33 20,40 55,50 140.11003AD 500 Bar
Q140-F04RP 1/4 Coupler 1/4” BSPPF 700
Q140-M04RP 1/4 Nipple 1/4” BSPPF 700
Q140-F06RP 3/8 Coupler 3/8” BSPPF 600
Q140-M06RP 3/8 Nipple 3/8” BSPPF 600
Q140-F08RP 1/2 Coupler 1/2” BSPPF 500
Q140-M08RP 1/2 Nipple 1/2” BSPPF 500

316 STAINLESS STEEL 140 SERIES

WATER BLAST FEMALE (CARBON ST.)

DN ØA CH2 B ØD L REF.
• 316 Stainless Steel
• Free flow, No Poppet Valves 06 ¼” BSP 22 35 29,50 45,10 140.12011AB 700 Bar
• High Pressure Ratings 10 ⅜” BSP 27 38 34 48,50 140.12012AC 600 Bar
• For use with water blasters 13 ½” BSP 32 45 39,50 55,50 140.12013AD 500 Bar

Part No Body Description Connection Working
Size (“) Pressure
(Bar)
Q140S-F04RP 1/4 Coupler 1/4” BSPPF 300
Q140S-M04RP 1/4 Nipple 1/4” BSPPF 300
Q140S-F06RP 3/8 Coupler 3/8” BSPPF 280
Q140S-M06RP 3/8 Nipple 3/8” BSPPF 280
Q140S-F08RP 1/2 Coupler 1/2” BSPPF 250
Q140S-M08RP 1/2 Nipple 1/2” BSPPF 250

***NOTE** See Page J32 for technical details

J14
