BSPP X BSPP FEMALE ADAPTOR BSPP X BSPP FEMALE

EXTENSION ADAPTOR continued

A B
A10200606E32 3/8” 3/8” 32
A10200606E45 3/8” 3/8” 45
A10200606E50 3/8” 3/8” 50
Part No Thread A Thread B
A10200606E57 3/8” 3/8” 57
(BSPP) (BSPPF) A10200808E35 1/2” 1/2” 35
A10200204 1/8” 1/4” A10200808E40 1/2” 1/2” 40
A10200206 1/8” 3/8” A10200808E51 1/2” 1/2” 51
A10200402 1/4” 1/8” A10200808E60 1/2” 1/2” 60
A10200406 1/4” 3/8” A10200808E80 1/2” 1/2” 80
A10200408 1/4” 1/2” A10201212E48 3/4” 3/4” 48
A10200412 1/4” 3/4” A10201212E56 3/4” 3/4” 56
A10200604 3/8” 1/4” A10201212E73 3/4” 3/4” 73
A10200608 3/8” 1/2”
A10201616E54 1” 1” 54
A10200612 3/8” 3/4”
A10201616E84 1” 1” 84
A10200806 1/2” 3/8”
A10200812 1/2” 3/4”
A10200816 1/2” 1”
A10200820 1/2” 1.1/4” NPT X NPT FEMALE REDUCING
A10201208 3/4” 1/2” BUSH
A10201216 3/4” 1”
A10201220 3/4” 1.1/4”
A10201224 3/4” 1.1/2”
A10201612 1” 3/4” A B
A10201620 1” 1.1/4”
A10201624 1” 1.1/2”
A10202016 1.1/4” 1”
Part No Thread A Thread B
A10202024 1.1/4” 1.1/2”
(NPT) (NPTF)
A10202032 1.1/4” 2”
A34360402 1/4” 1/8”
A10202420 1.1/2” 1.1/4”
A34360602 3/8” 1/8”
A10202432 1.1/2” 2”
A34360604 3/8” 1/4”
BSPP X BSPP FEMALE EXTENSION A34360802 1/2” 1/8”
A34360804
1/4”
1/2”
ADAPTOR A34360806 1/2” 3/8”
A34361204 3/4” 1/4”
A B A34361206 3/4” 3/8”
A34361208 3/4” 1/2”
A34361604 1” 1/4”
C A34361606 1” 3/8”
A34361608 1” 1/2”
Part No Thread A Thread B Dim C A34361612 1” 3/4”
(BSPP) (BSPPF) (mm) A34362008 1.1/4” 1/2”
A10200202E28 1/8” 1/8” 28 A34362012 1.1/4” 3/4”
A10200202E38 1/8” 1/8” 38 A34362016 1.1/4” 1”
A10200202E48 1/8” 1/8” 48 A34362412 1.1/2” 3/4”
A10200404E33 1/4” 1/4” 33 A34362416 1.1/2” 1”
A10200404E41 1/4” 1/4” 41 A34362420 1.1/2” 1.1/4”
A10200404E55 1/4” 1/4” 55 A34363220 2” 1.1/4”
A10200404E59 1/4” 1/4” 59 A34363224 2” 1.1/2”
