UNO X JIC FEMALE SWIVEL BSPP X ORFS FEMALE SWIVEL
ADAPTOR ADAPTOR

A B A B

Part No Thread A Thread B Part No Thread A Thread B
(UNO) (JICFS) (BSPP) (ORFSFS)
A56530707 7/16” 7/16” A10890209 1/8” 9/16”
A56530909 9/16” 9/16” A10890409 1/4” 9/16”
A56531212 3/4” 3/4” A10890411 1/4” 11/16”
A56531414 7/8” 7/8” A10890611 3/8” 11/16”
A56531717 1.1/16” 1.1/16” A10890613 3/8” 13/16”
A56532121 1.5/16” 1.5/16” A10890813 1/2” 13/16”
A56532626 1.5/8” 1.5/8” A10890816 1/2” 1”
A56533030 1.7/8” 1.7/8” A10891219 3/4” 1.3/16”
A10891623 1” 1.7/16”
A10892019 1.1/4” 1.3/16”
UNO X ORFS FEMALE SWIVEL A10892027 1.1/4” 1.11/16”
2”
A10892432
1.1/2”
ADAPTOR

A B

Part No Thread A Thread B
(UNO) (ORFSFS)
A56890709 7/16” 9/16”
A56890911 9/16” 11/16”
A56891213 3/4” 13/16”
A56891416 7/8” 1”
A56891719 1.1/16” 1.3/16” JIC X ORFS FEMALE SWIVEL
A56892123 1.5/16” 1.7/16” ADAPTOR
A56892627 1.5/8” 1.11/16”
A56893032 1.7/8” 2”
A B
UNO X BSPP FEMALE SWIVEL
ADAPTOR
Part No Thread A Thread B
(JIC) (ORFSFS)
A B A50890709 7/16” 9/16”
A50890911 9/16” 11/16”
A50891213 3/4” 13/16”
Part No Thread A Thread B A50891416 7/8” 1”
(UNO) (BSPPFS)
A50891719 1.1/16” 1.3/16”
A56171206 3/4” 3/8”
A50892123 1.5/16” 1.7/16”
A56171208 3/4” 1/2” A50892627 1.5/8” 1.11/16”
A56171408 7/8” 1/2”
A56171712 1.1/16” 3/4”
