Aqua-Traxx Drip Tape Fittings
®

Use to connect Aqua-Traxx drip tube run
®
lengths to various submains.

Aqua-Traxx Fittings
®
Tube Size
Description Use Drawing
16 mm 22 mm
Tape Joiner Used for joining or repairing tape 1014100 1014111
lines
Tape Joiner × Used for connecting riser tube to 1014104
Barb tape 16 mm Barb ×
16 mm Tape
(use Drip-In plain
poly 1015659)
10 mm Used to turn off supply to tape 1014106
Compression lines, when connected to Durapol
× Tape In-Line
Tap
Tape Tee Used for connection of tape × 1014109
tape × tape

Two Stage Used for connecting Aqua-Traxx 1014099 (double
Layflat tape to Lay-Flat tubing (16 mm spigot)
Adaptor diameter hole required)

One Stage Used for connecting Aqua-Traxx 1014103
Layflat tape to Lay-Flat tubing (19 mm
Adaptor diameter hole required)

Drip-In Tubing Used for riser tube from the 1015659 (OD 16 mm) 1015660 (OD 20 mm)
uPVC submains (Plain tube, no (ID 14 mm) 450 m (ID 18 mm) 300 m
emitters) roll roll

Grommet Used for connecting Aqua-Traxx 1015678 1015681
Take-Off via plain Drip-In riser to uPVC (hole saw 5/8˝) (hole saw 5/8˝)
Complete submains (min 32 mm size)
