Drip-Loc Fittings cont.
oc
® ®
Drip-Loc Fittings Ordering Information
®
Tube Size (ID)
Description Use Image
13 mm 16 mm 19 mm 25 mm
Drip-Loc Tee Used for connecting 1011201
®
two (2) driplines to a
submain riser
®
Drip-Loc Joiner Used for joining or 1011211 1011212
repairing driplines
®
Drip-Loc Used for changing 1011217
Reducing Joiner tubing sizes in long (16 mm × 13
lateral runs mm)
Drip-Loc Used for connecting 1011191 1011192 1011193 1011194
®
Grommet Take driplines to uPVC
Off Complete* submains (min 40 mm
size)
Rubber Top Hat Combine with suitable 101THG13 101THG16 101THG19
Grommet barbed fittings to (use with (use with
offtake 10144705) 10144715)
LD poly from PVC
Rubber Grommet Grommet spare part 1011196 1011198 1011198 1011199
for Drip-Loc for Drip-Loc Grommet
®
only take off complete
®
Drip-Loc End Used to seal the ends 1011231
Stop of driplines
®
* Drip-Loc Grommet Off-Takes are used for connecting polyethylene tubing to uPVC submains. The curved rubber grommet fits snugly to the uPVC
tubing. See previous page for hole saw sizes.

Drip-Loc Fittings to suit Drip-In Tube
®
Drip-In Tube Size
Description Use Image
16 mm (OD) 20 mm (OD)
Drip-Loc Used for joining or repairing 1011211
®
Joiner driplines
Drip-Loc Used for connecting driplines to 1011191 (use 5/8˝ or 1011193 (use 7/8˝ or
®
Grommet Take uPVC submains ( min 40 mm size) 16 mm hole saw) 22 mm hole saw)
Off
Drip-Loc Tee Used for connection of two (2) 1011201
®
driplines to a submain riser
Drip-Loc End Used to seal the ends of driplines 1011231
®
Stop
