Troubleshooting

13-3-1 DTCs [EV-ECU related 2 / 5 ]

DTC Description
P0A0A Inter lock SW
P0A10 DCDC converter fail (2)
P0A2A Motor coil TEMP. sensor(MCU)
P0A3D IGBT2 temperature high(MCU)
P0A51 Current sensor(MCU)
P0A78 IGBT fail(MCU)
P0A90 Motor over current 2 (MCU)
P0AA1 Main contactor P weld
P0AA4 Main contactor N weld
P0ABA Motor drive voltage sensor(MCU)
P0ABF Battery current sensor(BMU)
P0ADB Main contactor P circuit low
P0ADF Main contactor N circuit low
P0AE2 Pre-charge contactor weld
P0AE6 Pre-charge contactor circuit low
P0AE7 Pre-charge contactor circuit HI
P0AED IGBT temperature sensor(MCU)
P0C73 Water pump (low speed)
P0C74 Water pump (high speed)
P1602 System LSI communication

P1A00 APS(main) power supply circuit
P1A01 APS(sub) power supply circuit
P1A02 Shift position SW :P
P1A03 Shift position SW :R
P1A04 Shift position SW :N
P1A05 Shift position SW :D
P1A06 Shift position SW :E
P1A07 Shift position SW :B
P1A08 Inhibitor SW :P
P1A09 Inhibitor SW :R
P1A0A Inhibitor SW :N
P1A0B Inhibitor SW :D
P1A0C Inhibitor SW :B
P1A0D Inhibitor SW :E
P1A0E Backlamp relay circuit low
P1A0F Backlamp relay circuit high
P1A10 OBC power supply circuit low
P1A11 OBC power supply circuit high
P1A12 OBC abnormal stop
P1A14 Quick CHG.contactor circuit low
