52

Thermic fluid heater operator should check and monitor on regular basis,

1) Flame geometry / pattern inside the combustion zone

2) Stack temperature

3) Oxygen percentage in flue gas at chimney sampling point and

4) Regular inhouse checking of quality of diesel i.e Sp.gravity and

5) Random sampling of diesel tanker for ultimate analysis through accredited testing
laboratory.

Ultimate analysis includes,

1) Hydrogen %
2) Oxygen %
3) Sulpher %
4) Carbon %
5) Moisture content %
6) Ash content %
7) Specific Gravity %
8) Calorific value kCal/kg (Gross CV and Net CV)

This ultimate analysis of fuel helps facility dept to keep close eye on daily performance of
Thermic fluid heater unit. As we run Thermic fluid heater effectively, maximum efficiency
would definitely achieved.

Case study: M/s Arabian Flexible Packaging LLC, Dubai

Equipment code: Thermax Delta therm make 15, 00,000 kCal/hr @ 280°C
Thermic fluid heater Assessment

Table 11. Details of thermic fluid heater

Sr.no. Description Thermic fluid heater no.1/2/3

Status Thermic fluid heater no.3 is on and other 2
& 3 are in shut off condition.
1 Make DELTA THERM (M/s Thermax Ltd.)

2 Model TPA-15/L/M/197

3 Capacity in Kcals/hr. 15,00,000 kCal/hr

4 Connected load, Kw 31 Kw
