CO METER เครื่องวัด CO

PONPE 408F PONPE 409F

Specifications
CO2 display range: 350ppm-3000ppm
Temperature display range: 0-50°C
Operating temperature: -10~ +50°C
Operating humidity: 5ˋRH-90ˋRH
Storage temperature: -10~+60°C
Storage humidity: ≤60ˋRH
Fixing hole distance: 60mm
Control power: ≤200W
Specifications

Project
HT-2000 Power supply Project Unit Parameter value
VAC
200~240
CO2 adjustment range PPM 350~1000
CO2 control range PPM 350~1500
CO2 measurement maximum PPM 1999
Temperature display range ˚C 0~50
Humidity display range %RH 5~99
Control power W ≤200
Rated Power W < 2
Dimensions MM 88×88×50
Wirings MM2 2 x 1.5 or 1 x 2.5
Install hole spacing MM 56~58
Protection Class IP 30
Flame retardant rating Level V0

Specifications
Carbon Dioxide: Range: 0-9999
Accuracy: ±50ppm ±5%rdg
Response Time: 10s
Temperature: Range: -10.0~70.0°C
Resolution: 0.1°C/°F
Humidity: Range: 0.1~99.9%
Resolution: 0.1%
Logging Memory: 12700
