KNX ADVANCED COURSE

5.1.4 AND Function with ON/OFF Delay

Configure a 4-fold switch actuator with the application "Switch Logic Default Time/2" and
activate the AND function in the parameters of channel A. Set the time delays shown in
the parameter window.

Figure 16: AND function with time delays

Test the function of the following sequences:
AND function without delay
AND function with ON delay
AND function with ON and OFF delay
Familiarise yourself with the flow diagrams in the section describing the AND function
(Case 1, Case 2, Case 3).
