Page 944 - YG 2019

JET-POWER JET-POWER
END MILLS EH969 SERIES PLAIN SHANK END MILLS EH970 SERIES PLAIN SHANK

CARBIDE, MULTI FLUTE 45° HELIX LONG LENGTH CARBIDE, MULTI FLUTE 45° HELIX LONG REACH
FINE PITCH ROUGHING FINE PITCH ROUGHING

▶Suitable for low hardness materials (under HRc45), alloy steels, tool steels, carbon steels, prehardened steels, stainless steel, titanium, inconel, ▶Suitable for low hardness materials (under HRc45), alloy steels, tool steels, carbon steels, prehardened steels, stainless steel, titanium, inconel,
nimonic, etc. nimonic, etc.
▶High chip removed and minimizing breakages of cutting edges. ▶High chip removed and minimizing breakages of cutting edges.
▶Corner Protection against chipping. ▶Corner Protection against chipping.

D3
D2 D1
L1
L3
L2

P.955 ◆ U.S.A Stock P.955 ◆ U.S.A Stock

Unit : Inch Unit : Inch
Mill
Neck
Shank
Length
Mill
Shank
EDP No. Diameter Diameter Length Overall No. of EDP No. Diameter Diameter Length Below Shank Overall Diameter No. of
Length
Flute
of Cut
of Cut
Length
Flute
95107 3/16 1/4 1/2 2-1/4 3 D1 D2 L1 L3 L2 D3
95108 1/4 1/4 3/4 2-1/2 4 95101 1/4 1/4 3/4 7/8 2-1/2 .230 4
95109 5/16 5/16 3/4 2-1/2 4 95102 5/16 5/16 3/4 1 2-1/2 .292 4
95110 3/8 3/8 7/8 2-1/2 4 95103 3/8 3/8 7/8 1-1/4 2-1/2 .355 4
95111 1/2 1/2 1 3 4 95104 1/2 1/2 1 1-1/2 3 .480 4
95112 5/8 5/8 1-1/4 3-1/2 5 95105 5/8 5/8 1-1/4 2 4 .605 5
95113 3/4 3/4 1-5/8 4 6 95106 3/4 3/4 1-5/8 2-3/8 4-3/8 .719 6
95114 1 1 1-3/4 4 6
Mill Dia. Mill Dia. Shank Dia.
Mill Dia. Mill Dia. Shank Dia. (inch) Tolerance(inch) Tolerance
(inch) Tolerance(inch) Tolerance 1/4~3/8 0 ~ -.0022
3/16 0 ~ -.0019 1/2~5/8 0 ~ -.0027 0 ~ -.0003
1/4~3/8 0 ~ -.0022 3/4~1 0 ~ -.0033
0 ~ -.0003
1/2~5/8 0 ~ -.0027
3/4~1 0 ~ -.0033 Enforced cutting edge
Enforced cutting edge

◎ : Excellent ◯ : Good ◎ : Excellent ◯ : Good
P H M K N S P H M K N S
Carbon Alloy Prehardened High Hardened High Carbon Alloy Prehardened High Hardened High
Steels Steels Steels Hardened Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature Steels Steels Steels Hardened Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Iron
Steels
Iron
Steels
~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
○ ◎ ◎ ○ ◎ ◎ ○ ○ ◎ ◎ ○ ◎ ◎ ○
944 • phone:+1-800-765-8665, Technical Support : 888-868-5988, www.yg1usa.com phone:+1-800-765-8665, Technical Support : 888-868-5988, www.yg1usa.com • 945
