END MILLS

2 Flutes
30˚ Helix
1.5x (SMS) and 3x (SM) Diameter Flute Lengths
Right Hand Spiral
Right Hand Cut
Dura Carb II for Enhanced Shock Resistance
Speeds and Feeds, see fullertontool.com

Tolerance:
Shank Diameter: h6
Cutter Diameter: +.0005” -.0005”
+0.02mm -0.02mm

Tool EDP Number
Cutting Diameter Length Cutting Shank Overall
Length Diameter Length
Style UC
.0050 SMS .0075 1/8 1 1/2 32540
.0060 SMS .0090 1/8 1 1/2 32541
.0070 SMS .0105 1/8 1 1/2 32542
.0080 SMS .0120 1/8 1 1/2 32543
.0090 SMS .0135 1/8 1 1/2 32544
SMS .0150 1/8 1 1/2 32352
.0100
SM .0300 1/8 1 1/2 30900
SMS .0165 1/8 1 1/2 32353
.0110
SM .0330 1/8 1 1/2 30901
SMS .0180 1/8 1 1/2 32354
.0120
SM .0360 1/8 1 1/2 30902
SMS .0195 1/8 1 1/2 32355
.0130
SM .0390 1/8 1 1/2 30903
SMS .0210 1/8 1 1/2 32356
.0140
SM .0420 1/8 1 1/2 30904
SMS .0225 1/8 1 1/2 32357
.0150
SM .0450 1/8 1 1/2 30905
SMS .0240 1/8 1 1/2 32358
.0160
SM .0480 1/8 1 1/2 30906
SMS .0255 1/8 1 1/2 32359
.0170
SM .0510 1/8 1 1/2 30907
SMS .0270 1/8 1 1/2 32360
.0180
SM .0540 1/8 1 1/2 30908
SMS .0285 1/8 1 1/2 32361
.0190
SM .0570 1/8 1 1/2 30909
SMS .0300 1/8 1 1/2 32362
.0200
SM .0600 1/8 1 1/2 30910
SMS .0315 1/8 1 1/2 32363
.0210
SM .0630 1/8 1 1/2 30911
SMS .0330 1/8 1 1/2 32364
.0220
SM .0660 1/8 1 1/2 30912
