SECTION 10.0 – TENDERER’S PROPOSAL AND SUBMISSION DOCUMENTATION SECTION 10.0 – TENDERER’S PROPOSAL AND SUBMISSION DOCUMENTATION

SECTION 10.0: TENDERER’S PROPOSAL AND SUBMISSIO DOCUMENTATION
10.3 DRAWINGS AND SCHEDULES

A. TENDERERS 10.3.1 All drawings submitted shall be in the metric system unit.

10.3.2 Drawings submitted shall consist of but not limited to the following:
10.1 DESIGN PROPOSAL
a) Key and Location Plan of the project site.
10.1.1 The design proposal shall be professionally developed and refined to meet
each type of building's proper functional requirements and each room's b) Master Plan of the entire site development, showing the layout of the
correct functioning. The proposal shall comply with the Local Authority buildings and infrastructure.
requirements and meet all other government agencies' regulatory
requirements and approvals. c) Detailed site layout of buildings, confined to the area to be developed
only, was accurately surveyed and presented in a minimum scale of
10.1.2 The tenderers are required to submit a design proposal consisting of a 1:500.
design report, drawings, specifications, schedules, calculations,
catalogues, etc., for the intended project in accordance with the work's d) Floor plans, elevations, sections, and perspective views (interior and
requirements. exterior) of all buildings.

10.1.3 Descriptions of planning principles and design descriptions shall be e) All relevant Interior Design.
submitted, complete with diagrams/charts of vehicular/pedestrian traffic
flow, security, and the various zones. f) Landscape drawings.

g) All other pertinent support drawings for evaluation purposes.
10.2 DESIGN REPORT
10.3.3 The drawings shall indicate building materials and finishes for floors,
10.2.1 Design report shall consist of but not limited to the followings: walls, ceilings, roofs, and structural components to be used.

a) Planning and design concepts and principles of the proposal. 10.3.4 Floor plans shall also indicate the position and extent (length and height)
of the built-in furniture and equipment proposed. A detailed design of built-
b) Design descriptions of the proposal. in furniture shall be produced after the award of the tender.

c) Schematic drawings and sketches showing design intent. 10.3.5 Plans and drawings shall clearly indicate the name, use, room code,
finishes, and size of every room or area.
d) Diagrams and activity workflow (zoning, circulation, etc.)
10.3.6 All areas and rooms shall be indicated the type of ventilation in the floor
e) Proposed design work programme. plans.

f) IBS Score Calculation.
10.3.7 Landscape Drawings
g) Proposal of Master key System.
Landscape drawings shall consist of hard and soft landscaping works,
h) Proposal of Internal and External Signages. complete with specifications of both landscaping materials. The tenderer is
required to submit one (1) complete set of design proposal consisting of
the brief write-up, design concept, drawings, specifications, and schedules
but not be limited to the following:

98 99
2021 EDITION HEALTH FACILITY ARCHITECTURAL NEEDS STATEMENT 2021 EDITION HEALTH FACILITY ARCHITECTURAL NEEDS STATEMENT
