Page 646 - Deko-Light Light Impressions 2019-20
P. 646
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 8 x 2 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 3 cables [V-, V+]
840097 3000 - 6500 K 600 LEDs 38 W 2500 lm / Stripe 500 lm / Meter EEI: A
12 SMD - 15°C M M
3528 120° 2 CH IP20 + 50°C
Cutting option
over to 50 mm / 6 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 10 x 2 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 3 cables [V-, V+]
840142 3000 - 6500 K 600 LEDs 46 W 3600 lm / Stripe 720 lm / Meter EEI: A
12 SMD 120° 2 CH IP20 - 15°C M M
3528 + 50°C
Cutting option
over to 25 mm / 3 LED
LED-STRIPES | 2 Channel 645
