Page 650 - Deko-Light Light Impressions 2019-20

Width Voltage Power / m Light color Strahlungsverteilung Luminous flux / m LEDs / m Length Protection class Article Catalogue page

5 mm 24V DC 9,4 W 450 - 630 nm 400 lm 120 5000 mm IP20 840276 650
8 mm 24V DC 12,4 W 450 - 630 nm 400 lm 60 5000 mm IP44 840264 658
8 mm 24V DC 14,0 W 450 - 630 nm 433 lm 60 3000 mm IP44 840263 657
8 mm 24V DC 14,0 W 450 - 630 nm 433 lm 60 3000 mm IP20 840261 650
10 mm 12V DC 6,7 W 450 - 630 nm 183 lm 30 3000 mm IP33 840075 656
10 mm 12V DC 8,0 W 450 - 630 nm 280 lm 60 5000 mm IP20 840250 651
10 mm 12V DC 10,7 W 450 - 630 nm 383 lm 60 3000 mm IP20 840249 651
10 mm 24V DC 7,2 W 450 - 630 nm 170 lm 30 5000 mm IP33 532551 657
10 mm 24V DC 7,2 W 450 - 630 nm 183 lm 30 3000 mm IP33 532351 656
10 mm 24V DC 12,0 W 450 - 630 nm 400 lm 60 5000 mm IP44 840255 658
10 mm 24V DC 12,0 W 484 nm 400 lm 60 5000 mm IP20 840254 652
10 mm 24V DC 13,0 W 486 nm 520 lm 96 5000 mm IP20 840147 653
10 mm 24V DC 13,3 W 450 - 630 nm 433 lm 60 3000 mm IP20 840253 652
10 mm 24V DC 20,0 W 450 - 630 nm 667 lm 96 3000 mm IP20 840257 653
12 mm 12V DC 4,4 W 450 - 630 nm 150 lm 30 5000 mm IP67 840103 659
12 mm 12V DC 5,6 W 450 - 630 nm 200 lm 30 5000 mm IP20 843213 654
12 mm 24V DC 6,4 W 450 - 630 nm 220 lm 30 5000 mm IP20 843246 654
12 mm 24V DC 7,0 W 450 - 630 nm 200 lm 30 10000 mm IP20 840247 655
13 mm 12V DC 8,0 W 450 - 630 nm 280 lm 60 5000 mm IP67 840252 659
13 mm 24V DC 12,0 W 450 - 630 nm 400 lm 60 5000 mm IP67 840256 660
15 mm 24V DC 6,7 W 450 - 630 nm 173 lm 30 15000 mm IP20 840248 655
15 mm 24V DC 13,0 W 450 - 630 nm 520 lm 96 5000 mm IP67 840148 660

3 CHANNEL
Along with base colours red, green and blue, 3 channel Stripes
also offer all mixed colours in an additive colour scope.

LED-STRIPES | 3 Channel | Quick Finder 649
