Page 651 - Deko-Light Light Impressions 2019-20
P. 651
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 5 x 2 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
840276 450 - 630 nm 600 LEDs 47 W 2000 lm / Stripe 400 lm / Meter EEI: A
24 SMD - 15°C M M
3535 120° 3 CH IP20 + 50°C
Cutting option
over to 50 mm / 6 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 8 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
840261 450 - 630 nm 180 LEDs 42 W 1300 lm / Stripe 433 lm / Meter EEI: A
24 SMD 120° 3 CH IP20 - 15°C M M
5050 + 50°C
Cutting option
over to 100 mm / 6 LED
650 LED-STRIPES | 3 Channel
