Page 647 - Deko-Light Light Impressions 2019-20
P. 647
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 11 x 4,8 mm
LED rows: 1
Fixation: Incl. mounting set
Stripe connection: 3 cables [2x V-, V+]
840209 3000 - 6000 K 600 LEDs 36 W 2200 lm / Stripe 440 lm / Meter EEI: A
12 SMD 120° Ra>90 2 CH IP67 - 15°C M M
3528 + 50°C
Cutting option
over to 50 mm / 6 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 13 x 5,5 mm
LED rows: 1
Fixation: Incl. mounting set
Stripe connection: 3 cables [2x V-, V+]
840143 3000 - 6500 K 600 LEDs 46 W 3600 lm / Stripe 720 lm / Meter EEI: A
12 SMD 120° 2 CH IP67 - 15°C M M
3528 + 50°C
Cutting option
over to 25 mm / 3 LED
646 LED-STRIPES | 2 Channel
